42
HS-MB1
SECTION 6
ELECTRICAL PARTS LIST
A-1560-430-A MAIN BOARD, COMPLETE
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C2001 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2100 1-126-972-11 ELECT 1000uF 20% 50V
C2101 1-114-193-11 ELECT CHIP 470uF 20% 25V
C2103 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C2104 1-112-794-11 ELECT CHIP 470uF 20% 16V
C2105 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2106 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C2109 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2110 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2111 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C2112 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2114 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C2117 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C2118 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2119 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2120 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2121 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2122 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2123 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2124 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2125 1-126-950-11 ELECT 330uF 20% 35V
C2127 1-126-950-11 ELECT 330uF 20% 35V
C2128 1-126-950-11 ELECT 330uF 20% 35V
C2129 1-135-372-31 ELECT 470uF 20% 10V
C2130 1-128-949-31 ELECT 470uF 20% 16V
C2131 1-126-193-11 ELECT CHIP 1uF 20% 50V
C2132 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C2133 1-112-791-11 ELECT CHIP 100uF 20% 16V
C2135 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C2136 1-128-962-31 ELECT 470uF 20% 50V
C2300 1-126-933-11 ELECT 100uF 20% 16V
C2301 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C2302 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C2303 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C2304 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C2305 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C2306 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2307 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2311 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2312 1-126-398-11 ELECT CHIP 4.7uF 20% 35V
C2313 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2314 1-126-398-11 ELECT CHIP 4.7uF 20% 35V
C2700 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2701 1-107-714-11 ELECT 10uF 20% 50V
0 C2702 1-113-925-11 CERAMIC 0.01uF 20% 250V
C2705 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C2706 1-107-714-11 ELECT 10uF 20% 50V
C2707 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C2708 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C2709 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C2710 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C2711 1-126-963-11 ELECT 4.7uF 20% 50V
C2712 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2714 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
0 C2716 1-113-925-11 CERAMIC 0.01uF 20% 250V
C2717 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2718 1-126-963-11 ELECT 4.7uF 20% 50V
C2719 1-126-960-11 ELECT 1uF 20% 50V
C2720 1-100-831-11 CERAMIC CHIP 0.001uF 2% 50V
C2721 1-107-714-11 ELECT 10uF 20% 50V
C2722 1-107-714-11 ELECT 10uF 20% 50V
C2723 1-126-963-11 ELECT 4.7uF 20% 50V
C2724 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C2746 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2747 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2748 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2900 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2901 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2902 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2903 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2904 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2905 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2906 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2907 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2908 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2909 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2910 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2911 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2912 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2913 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2914 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2915 1-126-197-11 ELECT CHIP 10uF 20% 50V
C2916 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C2917 1-126-933-11 ELECT 100uF 20% 16V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
MAIN
To Next Page
