Sony HS-MB1 - VIDEO Board; MAIN Board

HS-MB1
9
3-2. VIDEO BOARD
3-3. MAIN BOARD
 two screws
(+BVTP 3 × 8)
 three screws
(+BVTP 3 × 8)
RT VIDEO board
 CN310 (15P)
 CN320 (10P)

RB
 wire (flat type)(28 core)
(CN103)
 wire (flat type)(26 core)
(CN102)
 wire (flat type)(13 core)
(CN903)
 wire (flat type)(18 core)
(CN1110)
 wire (flat type)(25 core)
(CN705)
 three screws
(+BVTP 3 × 8)
 three screws
(+BVTP 3 × 8)
chassis (MB)
 MAIN board

