Sony HT-RT4 Service Manual

HT-RT4/RT40
HT-RT4/RT40
2626
5-6. SCHEMATIC DIAGRAM - EG4 OLED CHUKEI PC Board -
• See page 31 for IC Block Diagrams.
5-5. PRINTED WIRING BOARD - EG4 OLED CHUKEI PC Board -
• See page 24 for Circuit Boards Location. • : Uses unleaded solder.
1
A
B
C
D
E
F
2 3 4 56
D5000
C5000
R5001
R5002
111
2
10
12 13
CN5002
R5003
R5004
1
22
20
21
CN5004
R5005
R5006
R5007
R5008
C5015
C5010
C5014
C5018
C5011
C5007
C5001
R5000
C5008
R5009
C5020
6
1
7
8
CN5003
2
4
1
3
IC5002
6
1
7
8
CN5005
CL5025
1-982-181-
11
(11)
1-982-181-
11
(11)
EG4 OLED CHUKEI PC BOARD
EG4 OLED CHUKEI PC BOARD
(COMPONENT SIDE)
(CONDUCTOR SIDE)
>004P
TOUCH BOARD
CN4001
(Page 27)
>005P
CONNECTOR BOARD
CN5009
(Page 29)
ELEMENT, ORGANIC
EL INDICATOR
NFC MODULE
(RC-S730 (WW))
1
A
B
C
D
E
F
G
H
2 3 4 5 6 7 8 910
EG4 OLED CHUKEI PC BOARD
1
C5014
1
C5000
1
C5010
100P
C5015
100P
C5018
0.1
C5007
10C5008 0.1C5001
0.1
C5011
CL5025
6P
CN5005
1
UNSW3.3V
2
NFC_CLK
3
NFC_GND
4
NFC_DATA
5
NFC_IRQ
6
NFC_RFDET
6P
CN5003
1
UNSW3.3V
2
TS_CLK
3
TS_INT
4
TS_DATA
5
BT_LED
6
GND
CL-194S-HB8SP-SD-T
D5000
47
R5000
47
R5001
0
R5005
39K
R5007
0
R5002
22
R5008
0R5006
0
R5003
0
R5004
20P
CN5004
11P
CN5002
1O-LED_IXS
2
O-LED_CLK
3
O-LED_DOUT
4
O-LED_DC
5
O-LED_CSB
6
O-LED_RESET
7
UNSW3.3V
8
O-LED_IREF
9
VCC12V
10
VCC12V
11O-LED_GND
OUT
GND_2GND_1
VS
1KR5009
C5020
220P
1
SIRCS
2
TS_DATA
3
GND
GND
GND
4
TS_CLK
5
6
TS_INT
7
8
OLED_CLK
9
UNSW3.3V
10
OLED_DOUT
11
OLED_DC
12
OLED_CSB
13
OLED_RST
14
VCC12V
15
NFC_RFDET
16
NFC_IRQ
17
NFC_DATA
18
GND
19
NFC_CLK
20
UNSW3.3V
IC5002
SNM2140
IC5002
REMOTE CONTROL RECEIVER
3
3
ELEMENT,
ORGANIC
EL INDICATOR
>001S
TOUCH BOARD
CN4001
(Page 27)
>002S
CONNECTOR
BOARD
CN5009
(Page 29)
NFC MODULE
(RC-S730 (WW))

Sony HT-RT4 Specifications

General

Game mode	Yes
Audio decoders	Dolby Digital, Dolby Dual Mono
RMS rated power	- W
Audio output channels	5.1 channels
Subwoofer type	Active subwoofer
Cables included	Optical
Receiver included	-
Product color	Black
Audio formats supported	DTS, LPCM, PCM
Consumer Electronics Control (CEC)	BRAVIA Sync
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Power consumption (standby)	0.4 W
Power consumption (typical)	85 W

Weight and Dimensions

Depth	70 mm
Width	900 mm
Height	52 mm
Soundbar weight	2100 g
Subwoofer depth	315 mm
Subwoofer width	190 mm
Subwoofer height	392 mm
Subwoofer weight	7800 g
