Sony HT-RT4 Service Manual

HT-RT4/RT40
8
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
• JIG
When disassembling the unit, use the following jig (for speaker
removal).
Part No. Description
J-2501-238-A JIG FOR SPEAKER REMOVAL
2-4. LOUDSPEAKER 16CM
(Page 11)
2-5. CHASSIS SECTION
(Page 12)
2-2. FRONT PANEL SECTION-1
(Page 9)
2-6. BLUETOOTH MODULE
(Page 12)
2-3. FRONT PANEL SECTION-2
(Page 10)
2-7. SPEAKER CHUKEI PC BOAR BOARD
(Page 13)
2-8. MAIN BOARD (RT4),
EG4 MAIN BOARD (RT40),
CONNECTOR BOARD,
SWITCHING REGULATOR
(Page 14)
SET

Sony HT-RT4 Specifications

General

Game mode	Yes
Audio decoders	Dolby Digital, Dolby Dual Mono
RMS rated power	- W
Audio output channels	5.1 channels
Subwoofer type	Active subwoofer
Cables included	Optical
Receiver included	-
Product color	Black
Audio formats supported	DTS, LPCM, PCM
Consumer Electronics Control (CEC)	BRAVIA Sync
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Power consumption (standby)	0.4 W
Power consumption (typical)	85 W

Weight and Dimensions

Depth	70 mm
Width	900 mm
Height	52 mm
Soundbar weight	2100 g
Subwoofer depth	315 mm
Subwoofer width	190 mm
Subwoofer height	392 mm
Subwoofer weight	7800 g
