Sony HT-RT4 Service Manual

HT-RT4/RT40
7
MODEL IDENTIFICATION
Distinguish by Part No. on the rear side of a main unit.
– Rear View –
Part No.
Destination Code
MODEL NUMBER LABEL
MADE IN MALAYSIA
MODEL :
&(17(5 )52175 )5217/
21/<)256657 21/<)2566657
6855 685/
63($.(56
+'0,287
$5&
79,1
237,&$/
$1$/2*,1
SA-WRT4
ACTIVE SUBWOOFER
Model Part No.
AEP
4-693-264-1[]
UK
4-693-264-2[]
E12
4-693-264-3[]
AUS
4-693-264-4[]
SP
4-693-264-5[]
LA9
4-693-264-6[]
AR
4-693-264-7[]
EA
4-693-264-8[]
E3
4-693-265-1[]
• Abbreviation
AR : Argentina model
AUS : Australian model
E3 : 240 V AC area in E model
E12 : 220-240 V AC area in E model
EA : Saudi Arabia model
LA9 : Latin-American model
SP : Singapore model
3. MAIN board (RT4) or EG4 MAIN board (RT40)
C1008
C1043
C1040
C1009
CN3400
*
The portion which applies bond:
– MAIN Board (RT4) or EG4 MAIN Board (RT40)
(Component Side) –
