Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
56
R173 1-216-025-91 RES,CHIP 100 5% 1/10W
R175 1-216-025-91 RES,CHIP 100 5% 1/10W
R176 1-216-073-00 METAL CHIP 10K 5% 1/10W
R177 1-216-073-00 METAL CHIP 10K 5% 1/10W
R178 1-216-073-00 METAL CHIP 10K 5% 1/10W
R179 1-216-025-91 RES,CHIP 100 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
************************************************************
* 1-669-420-11 CD PANEL BOARD
***************
< CONNECTOR >
CNL102 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D221 8-719-071-41 DIODE SELS5923C-TP15 (PBC OFF)
D222 8-719-071-41 DIODE SELS5923C-TP15 (VCD)
D223 8-719-071-41 DIODE SELS5923C-TP15 (PBC)
D224 8-719-071-42 DIODE SEL5723C-TP15 (O)
D225 8-719-071-42 DIODE SEL5723C-TP15 (O)
D226 8-719-046-80 DIODE SML19416W-TP4 (1)
D227 8-719-046-80 DIODE SML19416W-TP4 (2)
D228 8-719-046-80 DIODE SML19416W-TP4 (3)
D229 8-719-071-42 DIODE SEL5723C-TP15 (PLAY)
D230 8-719-071-41 DIODE SELS5923C-TP15 (PAUSE)
< TRANSISTOR >
Q211 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q212 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q213 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q214 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q215 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q216 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q217 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q218 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q219 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q220 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q221 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q222 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q223 8-729-029-21 TRANSISTOR DTA114ESA-TP
< RESISTOR >
R241 1-249-410-11 CARBON 270 5% 1/4W F
R242 1-249-410-11 CARBON 270 5% 1/4W F
R243 1-249-410-11 CARBON 270 5% 1/4W F
R244 1-249-406-11 CARBON 120 5% 1/4W F
R245 1-249-406-11 CARBON 120 5% 1/4W F
R246 1-249-406-11 CARBON 120 5% 1/4W F
R247 1-249-406-11 CARBON 120 5% 1/4W F
R248 1-249-406-11 CARBON 120 5% 1/4W F
R249 1-249-406-11 CARBON 120 5% 1/4W F
R250 1-249-406-11 CARBON 120 5% 1/4W F
R251 1-249-406-11 CARBON 120 5% 1/4W F
R252 1-249-406-11 CARBON 120 5% 1/4W F
R253 1-249-410-11 CARBON 270 5% 1/4W F
R261 1-249-401-11 CARBON 47 5% 1/4W F
R262 1-249-403-11 CARBON 68 5% 1/4W F
R263 1-247-807-31 CARBON 100 5% 1/4W
R264 1-249-407-11 CARBON 150 5% 1/4W F
R265 1-249-407-11 CARBON 150 5% 1/4W F
R266 1-249-409-11 CARBON 220 5% 1/4W F
R267 1-249-411-11 CARBON 330 5% 1/4W
R268 1-249-413-11 CARBON 470 5% 1/4W F
R269 1-249-415-11 CARBON 680 5% 1/4W F
R270 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S270 1-762-751-11 SWITCH, TACTILE (PLAY PAUSE)
S271 1-762-751-11 SWITCH, TACTILE (STOP)
S272 1-762-751-11 SWITCH, TACTILE (OPEN/CLOSE)
S273 1-762-751-11 SWITCH, TACTILE (3)
S274 1-762-751-11 SWITCH, TACTILE (2)
S275 1-762-751-11 SWITCH, TACTILE (1)
S276 1-762-751-11 SWITCH, TACTILE (DISC SKIP/EX-CHANGE)
S277 1-762-751-11 SWITCH, TACTILE (PREV)
S278 1-762-751-11 SWITCH, TACTILE (RETURN)
S279 1-762-751-11 SWITCH, TACTILE (SELECT)
S280 1-762-751-11 SWITCH, TACTILE (NEXT)
************************************************************
* 1-658-575-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR BA1A4M-TP
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
BD CD PANEL CONNECTOR LEAF SW
