Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
59
R337 1-249-417-11 CARBON 1K 5% 1/4W F
R338 1-249-411-11 CARBON 330 5% 1/4W
R339 1-249-437-11 CARBON 47K 5% 1/4W
R340 1-249-437-11 CARBON 47K 5% 1/4W
R341 1-249-417-11 CARBON 1K 5% 1/4W F
R342 1-249-411-11 CARBON 330 5% 1/4W
R343 1-249-437-11 CARBON 47K 5% 1/4W
R351 1-249-435-11 CARBON 33K 5% 1/4W
R352 1-249-421-11 CARBON 2.2K 5% 1/4W F
R353 1-247-807-31 CARBON 100 5% 1/4W
R354 1-247-807-31 CARBON 100 5% 1/4W
R355 1-249-421-11 CARBON 2.2K 5% 1/4W F
R356 1-249-428-11 CARBON 8.2K 5% 1/4W F
R357 1-249-428-11 CARBON 8.2K 5% 1/4W F
R358 1-249-425-11 CARBON 4.7K 5% 1/4W F
R359 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-417-11 CARBON 1K 5% 1/4W F
R705 1-249-438-11 CARBON 56K 5% 1/4W
R706 1-249-417-11 CARBON 1K 5% 1/4W F
R754 1-249-417-11 CARBON 1K 5% 1/4W F
R755 1-249-438-11 CARBON 56K 5% 1/4W
R756 1-249-417-11 CARBON 1K 5% 1/4W F
R855 1-249-417-11 CARBON 1K 5% 1/4W F
R859 1-249-417-11 CARBON 1K 5% 1/4W F
! R861 1-212-853-00 FUSIBLE 6.8 5% 1/4W F
! R862 1-212-853-00 FUSIBLE 6.8 5% 1/4W F
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K (REC LEVEL L)
RV351 1-238-600-11 RES, ADJ, CARBON 10K (REC LEVEL R)
< VIBRATOR >
X101 1-760-489-11 VIBRATOR, CERAMIC 5MHz
************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 30% 16V
C804 1-162-306-11 CERAMIC 0.01uF 30% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-921-48 DIODE MTZJ-T-72-5.6C
D804 8-719-911-19 DIODE 1N4148M-TP
D805 8-719-911-19 DIODE 1N4148M-TP
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE)
************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
************************************************************
* 1-669-418-11 REG BOARD
**********
7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 N-S
< CAPACITOR >
C850 1-164-159-11 CERAMIC 0.1uF 50V
C851 1-164-159-11 CERAMIC 0.1uF 50V
C852 1-164-159-11 CERAMIC 0.1uF 50V
C855 1-164-159-11 CERAMIC 0.1uF 50V
C865 1-104-664-11 ELECT 47uF 20% 25V
C866 1-104-664-11 ELECT 47uF 20% 25V
< DIODE >
D851 8-719-911-19 DIODE 1SS133T-72
D852 8-719-911-19 DIODE 1SS133T-72
< IC >
IC851 8-759-231-58 IC M5F7812L
IC852 8-759-231-53 IC M5F7805L
IC853 8-759-604-86 IC M5F7807L
IC854 8-759-231-53 IC M5F7805L
************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< IC >
IC702 8-749-924-18 PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 PHOTO REFLECTOR GP2S28
MOTOR (SLIDE) MOTOR (TURN) REG SENSOR
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
