Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
61
C402 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C403 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C404 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C405 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C406 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C407 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C408 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C409 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C410 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C411 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C412 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C413 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C452 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C501 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C502 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C503 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C504 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C505 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C506 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C507 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C509 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C510 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C531 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C532 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C535 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C536 1-126-193-11 ELECT 1uF 20% 50V
C537 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C539 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C540 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C541 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C542 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C543 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C544 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C545 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C546 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C547 1-126-193-11 ELECT 1uF 20% 50V
C548 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C549 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C550 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C551 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C552 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C553 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C555 1-124-779-00 ELECT CHIP 10uF 20% 16V
C556 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C559 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C560 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C561 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
C562 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C563 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C564 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C565 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C566 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C568 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C569 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C570 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C573 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C574 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C576 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C577 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
< CONNECTOR >
* CN301 1-564-506-11 PLUG, CONNECTOR 3P
CN501 1-770-706-11 CONNECTOR, FFC/FPC 23P
CN503 1-779-416-11 CONNECTOR,FFC(LIF(NON-ZIF))13P
< TRIMMER >
CT503 1-141-539-11 CAP, ADJ 10PF (VIDEO FREQUENCY)
< DIODE >
D301 8-719-054-23 DIODE RB706D-40-T146
D501 8-719-422-12 DIODE UDZ-TE-17-3.9B
D502 8-719-018-51 DIODE CL-170R-CD-T (SELF DIAGNOSIS)
< IC >
IC101 8-759-701-39 IC NJM2100M(TE2)
IC401 8-759-262-00 IC MC14576CFEL
IC402 8-759-564-64 IC M38513M4-C50FP-TP
IC501 8-759-269-92 IC SN74HCU04ANSR
IC502 8-759-582-84 IC M30620MC-313FP
IC504 8-759-269-92 IC SN74HCU04ANSR
IC505 8-759-535-48 IC CL680T-D1
IC506 8-759-573-23 IC LC372100PM-J48-TLA
IC507 8-759-342-01 IC MB814260-70PJEQ
IC509 8-759-535-62 IC PCM1727E-2/T2
< JACK >
J301 1-537-943-11 TERMINAL, S (S VIDEO OUT)
< JUMPER RESISTOR >
JW101 1-216-295-91 SHORT 0
JW201 1-216-295-91 SHORT 0
JW401 1-216-295-91 SHORT 0
JW402 1-216-295-91 SHORT 0
JW403 1-216-295-91 SHORT 0
JW404 1-216-295-91 SHORT 0
JW405 1-216-295-91 SHORT 0
JW413 1-216-295-91 SHORT 0
JW502 1-216-295-91 SHORT 0
JW503 1-216-295-91 SHORT 0
JW504 1-216-295-91 SHORT 0
JW505 1-216-295-91 SHORT 0
< COIL >
L301 1-410-372-21 INDUCTOR CHIP 1.8uH
L302 1-410-372-21 INDUCTOR CHIP 1.8uH
L501 1-216-296-91 SHORT 0
L502 1-216-296-91 SHORT 0
L503 1-216-296-91 SHORT 0
L504 1-410-375-11 INDUCTOR CHIP 3.3uH
L505 1-216-296-91 SHORT 0
L506 1-216-296-91 SHORT 0
L507 1-216-296-91 SHORT 0
L508 1-216-296-91 SHORT 0
L509 1-216-296-91 SHORT 0
L510 1-216-296-91 SHORT 0
VIDEO
