Sony HXR-MC1 Operating Guide Service Manual

2-8
HXR-MC1/MC1P
EXPLODED VIEW
HARDWARE LIST
2-2-6. LCD SECTION
Follow the disassembly in the numerical order given.
1 PD-374 Board (1-1 to 1-6)
2 LCD (2-1 to 2-2)
3 Speaker (3-1 to 3-3)
PD-374
2 LCD
1-1
(#9)
1-2
1-3
1-4
1-5
1-6E
1 PD-374 Board
2-1
2-2E
HELP09
3-1
(#9)
3-2
3-3E
3 Speaker
Ver. 1.1 2009.01
