5-11
Ref. No. Part No. Description Ref. No. Part No. Description
HXR-MC1/MC1P
R6912 1-240-695-91 METAL CHIP 1K 5% 1/20W
R6913 1-694-535-91 SHORT CHIP 0
R6914 1-694-535-91 SHORT CHIP 0
R6915 1-694-535-91 SHORT CHIP 0
R6916 1-218-990-81 SHORT CHIP 0
R6918 1-240-822-11 METAL CHIP 47K 0.5% 1/20W
R6937 1-218-990-81 SHORT CHIP 0
R6938 1-218-990-81 SHORT CHIP 0
R6939 1-218-990-81 SHORT CHIP 0
R6940 1-218-990-81 SHORT CHIP 0
R6941 1-218-990-81 SHORT CHIP 0
R6942 1-218-990-81 SHORT CHIP 0
R6943 1-218-990-81 SHORT CHIP 0
R6944 1-218-990-81 SHORT CHIP 0
R6946 1-218-990-81 SHORT CHIP 0
R6947 1-218-990-81 SHORT CHIP 0
R6948 1-216-864-11 SHORT CHIP 0
R6949 1-218-990-81 SHORT CHIP 0
R6950 1-218-990-81 SHORT CHIP 0
R6951 1-216-864-11 SHORT CHIP 0
R6952 1-218-990-81 SHORT CHIP 0
R6953 1-216-295-91 SHORT CHIP 0
R6954 1-216-295-91 SHORT CHIP 0
A-1665-153-A CV-037 BOARD, COMPLETE
**********************
< CAPACITOR >
C7101 1-164-878-11 CERAMIC CHIP 150PF 5% 50V
C7102 1-164-876-11 CERAMIC CHIP 120PF 5% 50V
< CONNECTOR >
* CN7101 1-820-778-11 CONNECTOR, BOARD TO BOARD
* CN7102 1-817-262-21 HEADER ASSEMBLY (FOR PWB) 20P
CN7103 1-816-928-11 PIN, CONNECTOR 22P
A-1528-452-A FP-902 FLEXIBLE BOARD, COMPLETE
******************************
< CONNECTOR >
* CN9022 1-820-778-11 CONNECTOR, BOARD TO BOARD
* CN9101 1-820-778-11 CONNECTOR, BOARD TO BOARD
A-1528-464-A FP-903 FLEXIBLE BOARD, COMPLETE
******************************
< CONNECTOR >
* CN9034 1-821-894-11 CONNECTOR, BOARD TO BOARD 80P
* CN9102 1-821-894-11 CONNECTOR, BOARD TO BOARD 80P
A-1665-152-A FP-994 FLEXIBLE BOARD, COMPLETE
******************************
< CONNECTOR >
0* CN00011-820-778-11 CONNECTOR, BOARD TO BOARD
A-1665-151-A FP-995 FLEXIBLE BOARD, COMPLETE
******************************
< CONNECTOR >
* CN1001 1-819-696-21 CONNECTOR, HDMI (HDMI OUT)
A-1665-150-A JK-378 BOARD, COMPLETE
**********************
(J7701 is not supplied, but this is included in JK-378 complete board.)
< CAPACITOR >
C7701 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7702 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7708 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C7709 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
0 CN7701 1-750-361-51 CONNECTOR, FFC/FPC (ZIF) 30P
CN7702 1-815-794-13 CONNECTOR (MULTIPLE) (A/V R)
0 CN7703 1-819-436-11 CONNECTOR (SQUARE TYPE) (USB) 5P
< FERRITE BEAD >
FB7705 1-400-927-31 BEAD, FERRITE (1005)
FB7706 1-400-927-31 BEAD, FERRITE (1005)
< JACK >
0 J7701 (Not supplied) CONNECTOR, DC-IN (7.2V)
(J7701 is supplied including in JK-378 complete board.)
< LINE FILTER >
LF7704 1-457-223-11 COMMON MODE CHOKE COIL
* LF7707 1-457-217-21 COMMON MODE CHOKE COIL
< RESISTOR >
R7716 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7717 1-218-990-81 SHORT CHIP 0
R7718 1-216-864-11 SHORT CHIP 0
R7719 1-218-990-81 SHORT CHIP 0
R7720 1-218-990-81 SHORT CHIP 0
R7721 1-218-990-81 SHORT CHIP 0
R7722 1-218-990-81 SHORT CHIP 0
R7723 1-218-990-81 SHORT CHIP 0
R7724 1-218-990-81 SHORT CHIP 0
R7725 1-218-990-81 SHORT CHIP 0
R7726 1-218-953-11 METAL CHIP 1K 5% 1/16W
< VARISTOR >
* VDR702 1-802-251-21 CHIP VARISTOR
* VDR703 1-802-251-21 CHIP VARISTOR
* VDR704 1-802-251-21 CHIP VARISTOR
CM-107 CV-037 FP-902 FP-903 FP-994 FP-995 JK-378
• Refer to page 5-1 for mark 0.
