Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
HXR-MC1/MC1P
CC-109 CM-107
A-1665-274-A CC-109 BOARD, COMPLETE
**********************
< CAPACITOR >
C7001 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7002 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7003 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7004 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7006 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
* CN7001 1-820-779-11 CONNECTOR, BOARD TO BOARD
* CN7002 1-817-262-21 HEADER ASSEMBLY (FOR PWB) 20P
CN7003 1-816-928-11 PIN, CONNECTOR 22P
< DIODE >
D7001 6-501-568-01 DIODE RB521CS-30T2R
D7003 6-501-568-01 DIODE RB521CS-30T2R
D7004 6-501-568-01 DIODE RB521CS-30T2R
D7005 6-501-568-01 DIODE RB521CS-30T2R
D7006 6-501-568-01 DIODE RB521CS-30T2R
D7008 6-501-568-01 DIODE RB521CS-30T2R
D7010 6-501-568-01 DIODE RB521CS-30T2R
D7011 6-501-568-01 DIODE RB521CS-30T2R
D7012 6-501-568-01 DIODE RB521CS-30T2R
D7013 6-501-568-01 DIODE RB521CS-30T2R
D7015 6-501-568-01 DIODE RB521CS-30T2R
D7016 6-501-568-01 DIODE RB521CS-30T2R
< LINE FILTER >
LF7001 1-457-223-11 COMMON MODE CHOKE COIL
LF7002 1-457-223-11 COMMON MODE CHOKE COIL
LF7003 1-457-223-11 COMMON MODE CHOKE COIL
LF7004 1-457-223-11 COMMON MODE CHOKE COIL
LF7005 1-457-223-11 COMMON MODE CHOKE COIL
< RESISTOR >
R7018 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7019 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7020 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7021 1-218-977-11 METAL CHIP 100K 5% 1/16W
A-1665-272-A CM-107 BOARD, COMPLETE
***********************
(IC6904 (CMOS imager) is not supplied, but this is included in CM-107
complete board.)
< CAPACITOR >
C6906 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6909 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6911 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6912 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6913 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6914 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6915 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6916 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6917 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6918 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6919 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6920 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
* C6921 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6922 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6923 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6924 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6925 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6926 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
* C6927 1-112-716-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6928 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6929 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6930 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6931 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6932 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6940 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6941 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
* C6943 1-100-735-91 CERAMIC CHIP 10uF 20% 4V
C6944 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
< CONNECTOR >
* CN6902 1-820-778-11 CONNECTOR, BOARD TO BOARD
< DIODE >
D6901 8-719-074-67 DIODE EDZ-TE61-5.6B
D6902 8-719-074-67 DIODE EDZ-TE61-5.6B
< IC >
IC6903 6-708-455-01 IC R1114Q271D-TR-FA
IC6904 (Not supplied) IC IMX030CHL-13 (CMOS IMAGER) (Note)
(IC6904 is supplied including in CM-107 complete board.)
< COIL >
L6901 1-414-842-21 INDUCTOR 15nH
L6902 1-414-842-21 INDUCTOR 15nH
L6903 1-414-842-21 INDUCTOR 15nH
L6904 1-414-842-21 INDUCTOR 15nH
L6905 1-414-842-21 INDUCTOR 15nH
L6906 1-414-842-21 INDUCTOR 15nH
L6907 1-414-842-21 INDUCTOR 15nH
L6908 1-414-842-21 INDUCTOR 15nH
L6909 1-414-842-21 INDUCTOR 15nH
L6910 1-414-842-21 INDUCTOR 15nH
< RESISTOR >
R6902 1-218-990-81 SHORT CHIP 0
R6905 1-218-990-81 SHORT CHIP 0
R6910 1-694-535-91 SHORT CHIP 0
R6911 1-694-535-91 SHORT CHIP 0
Note: Be sure to read “Precautions for Replacement of
Imager” on page 4-2 when changing the imager.
Note: イメージャの交換時は4 - 3 ページのイメージャ交
換時の注意を必ずお読みください。
