ICD-UX71/UX71F/UX81/UX81F/UX91F
27
Pin No. Pin Name I/O Description
P2 SCK1(P14) O Serial interface 1 clock signal output ADDA serial clock signal output
M4 SDO1(P15) O Serial interface 1 data signal output ADDA serial data signal output
L5 SDI1(P16) I Serial interface 1 data signal input ADDA serial data signal input
R1 TXD1(P2A) O UART1 transmission signal output SP/HP change signal output
T1 RXD1(P2B) O UART1 reception signal output SP shut down signal output
T2 TCLKA(P17) O Multiple timer external clock A signal output CPU core voltage change signal output
R3 TCLKB(P18) O Multiple timer external clock B signal output Battery level measure signal output
T3 TIOCA0(P19) I/O
Multiple timer input capture/output compare A0 signal input/output
Not used in this set. (Open)
R4 Vdd1 — Digital power supply pin (+1.0V)
R2 TIOCB0(P1A) I/O
Multiple timer input capture/output compare B0 signal input/output
D AMP output on/off select signal output
P3 TIOCA1(P1B) I/O
Multiple timer input capture/output compare A1 signal input/output
OP LED (red) signal output
P4 TIOCB1(P1C) I/O
Multiple timer input capture/output compare B1 signal input/output
OP LED (green) signal output
R5 TXDO(P1D) O UART transmission signal output
T4 RXDO(P1E) I UART reception signal output
N4 PO0 I/O Port pin 0 bit0 CPU power on signal output
P5 PO1 I/O Port pin 0 bit1 Connect to ground in this set.
R6 PO2 I/O Port pin 0 bit2 AUDIO power on signal output
T5 PO3 I/O Port pin 0 bit3 FM power on signal output
N5 PO4 I/O Port pin 0 bit4 Charge on signal output
M5 PO5 I/O Port pin 0 bit5 Charge measurement signal output
M6 XFCE2(P06) O Nand fl ash chip enable 2 signal output LCD reset signal output
T6 XFCE3(P07) O Nand fl ash chip enable 3 signal output Mute signal output
P6 Vdd1 — Digital power supply pin (+1.0V)
N6 Vss — Digital ground pin
R7 Vdd2 — Digital power supply pin (+3.1V)
M7 XFWE O Nand fl ash write enable signal output
N7 XFRE O Nand fl ash read enable signal output
T7 XALE O Nand fl ash address latch enable signal output
P7 XCLE O Nand fl ash command latch enable signal output
T8 XFCE1(P1F) O Nand fl ash chip enable 1 signal output
R8 XFCE0 O Nand fl ash chip enable 0 signal output
M8 XFWP O Nand fl ash write protect signal output
N8 XFBSY I Nand fl ash busy signal input
P8 FD0 I/O Nand fl ash data bit 0 signal input/output
R9 FD1 I/O Nand fl ash data bit 1 signal input/output
T9 FD2 I/O Nand fl ash data bit 2 signal input/output
P9 FD3 I/O Nand fl ash data bit 3 signal input/output
N9 FD4 I/O Nand fl ash data bit 4 signal input/output
M9 FD5 I/O Nand fl ash data bit 5 signal input/output
T10 FD6 I/O Nand fl ash data bit 6 signal input/output
R10 FD7 I/O Nand fl ash data bit 7 signal input/output
P10 Vdd1 — Digital power supply pin (+1.0V)
N10 Vss — Digital ground pin
M10 Vdd2 — Digital power supply pin (+3.1V)
N11 SDWP I SD card write protect signal input Connected to ground in this set.
T11 SDCD I SD card detect signal input Connected to ground in this set.
R11 SDCMD I/O SD card command signal input/output Connected to ground in this set.
P11 SDCLK O SD card clock signal output Not used in this set. (Open)
M11 SDAT1 I/O SD card data bit 0 signal input/output Connected to ground in this set.
T12 SDAT2 I/O SD card data bit 1 signal input/output Connected to ground in this set.
