Sony ICD-UX71 - Electrical Parts List; Passive Components List

35
ICD-UX71/UX71F/UX81/UX81F/UX91F
SECTION 6
ELECTRICAL PARTS LIST
A-1565-362-A AUDIO BOARD, COMPLETE
(UX71:AEP/UX81:AEP)
A-1565-700-A AUDIO BOARD, COMPLETE
(UX71F:EXCEPT LA/UX81F:EXCEPT LA/UX91F)
A-1565-702-A AUDIO BOARD, COMPLETE (UX71:LA/UX81:LA)
A-1567-613-A AUDIO BOARD, COMPLETE
(UX71F:LA/UX81F:LA)
**********************
< CAPACITOR >
C1000 1-164-931-11 CERAMIC CHIP 100PF 10% 50V
C1001 1-164-931-11 CERAMIC CHIP 100PF 10% 50V
C1002 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
C1003 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
C1004 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1006 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1007 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1008 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1010 1-100-661-11 TANTAL. CHIP 100uF 20% 4V
C1011 1-100-661-11 TANTAL. CHIP 100uF 20% 4V
C1017 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1018 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C1020 1-112-692-11 CERAMIC CHIP 0.001uF 5% 50V
C1021 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C1022 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C1023 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C1024 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C1025 1-165-887-11 CERAMIC CHIP 0.22uF 10% 6.3V
C1027 1-165-887-11 CERAMIC CHIP 0.22uF 10% 6.3V
C1030 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C1031 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C1032 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
(UX71F/UX81F/UX91F)
C1033 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
(UX71F/UX81F/UX91F)
C1035 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C1036 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1037 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C1038 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C1039 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1040 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1041 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C1042 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C1043 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C1044 1-164-931-11 CERAMIC CHIP 100PF 10% 50V
C1045 1-165-887-11 CERAMIC CHIP 0.22uF 10% 6.3V
C1046 1-165-887-11 CERAMIC CHIP 0.22uF 10% 6.3V
C1048 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1053 1-164-931-11 CERAMIC CHIP 100PF 10% 50V
(UX71F/UX81F/UX91F)
C1054 1-164-931-11 CERAMIC CHIP 100PF 10% 50V
(UX71F/UX81F/UX91F)
C1055 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(UX71F/UX81F/UX91F)
C1056 1-164-860-11 CERAMIC CHIP 27PF 5% 50V
(UX71F/UX81F/UX91F)
C1058 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
(UX71F/UX81F/UX91F)
C1059 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(UX71F/UX81F/UX91F)
C1060 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(UX71F/UX81F/UX91F)
C1061 1-100-966-11 CERAMIC CHIP 10uF 20% 10V
(UX71F/UX81F/UX91F)
C1064 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(UX71F/UX81F/UX91F)
C2000 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT LA)
C2002 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
(EXCEPT LA)
C2005 1-137-934-11 TANTAL. CHIP 47uF 20% 10V
C2006 1-137-934-11 TANTAL. CHIP 47uF 20% 10V
C2007 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C2009 1-100-966-11 CERAMIC CHIP 10uF 20% 10V
(EXCEPT LA)
C2010 1-114-176-21 TANTAL. CHIP 47uF 20% 10V
C2011 1-114-176-21 TANTAL. CHIP 47uF 20% 10V
C2014 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C2015 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C2018 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2020 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT LA)
C2022 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(EXCEPT LA)
C2023 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2024 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C2026 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C2028 1-164-848-11 CERAMIC CHIP 8PF 0.5PF 50V
C2029 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C2031 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2034 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2035 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2036 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2037 1-114-176-21 TANTAL. CHIP 47uF 20% 10V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CH : Chinese model
KR : Korean model
LA : Latin American model
AUDIO
When indicating parts by reference num-
ber, please include the board name.
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
