Sony ICD-UX71 - Active Components and Modules

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ICD-UX71/UX71F/UX81/UX81F/UX91F
36
C2038 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
(UX71F/UX81F/UX91F)
C2044 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2045 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
(EXCEPT LA)
C2046 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2047 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
(EXCEPT LA)
C2048 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2049 1-100-966-11 CERAMIC CHIP 10uF 20% 10V
C2050 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C3002 1-100-539-11 TANTAL. CHIP 47uF 20% 6.3V
C3003 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4002 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4003 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4004 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4006 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4007 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4008 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4009 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4010 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4011 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4012 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4013 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4014 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4015 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
< DIODE >
D1000 8-719-083-04 DIODE RSB6.8STE61
D1001 8-719-083-04 DIODE RSB6.8STE61
D1002 8-719-083-04 DIODE RSB6.8STE61 (UX71F/UX81F/UX91F)
D1003 8-719-083-04 DIODE RSB6.8STE61 (UX71F/UX81F/UX91F)
D1007 8-719-083-04 DIODE RSB6.8STE61
D1008 8-719-083-04 DIODE RSB6.8STE61
D1012 6-502-162-01 DIODE RN262CST2R (UX71F/UX81F/UX91F)
D1014 8-719-820-41 DIODE 1SS302
D1015 6-500-314-01 DIODE DAN222MT2L
D2000 6-502-324-01 DIODE DA221M-T2L (EXCEPT LA)
D2003 8-719-069-28 DIODE 1SS400TE-61
D2004 8-719-069-28 DIODE 1SS400TE-61
D2008 6-500-314-01 DIODE DAN222MT2L
D2009 8-719-081-34 DIODE RB160M-30TR
D2010 8-719-069-28 DIODE 1SS400TE-61
D2011 8-719-069-28 DIODE 1SS400TE-61
D3000 8-719-069-28 DIODE 1SS400TE-61
D4000 6-500-781-01 LED SML-521MUW (OPR)
D4004 6-502-197-01 LED SML-D12M8WT86SM (LCD BACK LIGHT)
D4005 6-502-197-01 LED SML-D12M8WT86SM (LCD BACK LIGHT)
< FERRITE BEAD >
FB1002 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB1003 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB1004 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB1005 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB1006 1-400-684-21 INDUCTOR, FERRITE BEAD
FB1007 1-400-684-21 INDUCTOR, FERRITE BEAD
FB1008 1-400-684-21 INDUCTOR, FERRITE BEAD
(UX71F/UX81F/UX91F)
FB1010 1-400-461-21 FERRITE, EMI (SMD) (1005)
FB1011 1-400-684-21 INDUCTOR, FERRITE BEAD
FB1012 1-400-684-21 INDUCTOR, FERRITE BEAD
FB1013 1-400-461-21 FERRITE, EMI (SMD) (1005)
(UX71F/UX81F/UX91F)
< IC >
IC1001 6-713-563-01 IC AK4645EZ-L
IC1002 6-713-511-01 IC LV24230LS-TLM-E (UX71F/UX81F/UX91F)
IC1003 6-707-110-01 IC LM4916LDX/NOPB
IC1004 6-704-927-01 IC SN74LVC2G66YZPR (UX71F/UX81F/UX91F)
IC2001 6-713-494-01 IC PST8408UL
IC2002 6-711-822-01 IC TK77335AM4
IC2003 6-713-522-01 IC XC9128D45CDR
IC2004 6-713-488-01 IC LTC3526LEDC
IC2005 6-713-507-01 IC XC9226A18CMR (EXCEPT LA)
IC2007 6-713-367-01 IC MM3273BURE
IC2008 6-713-491-01 IC MM3272JURE
IC2012 6-713-523-01 IC MM3273AURE
IC2013 6-707-702-01 IC NJM2746RB1(TE2) (EXCEPT LA)
IC3000 6-711-104-01 IC RTC-4574NB
< COIL >
L1000 1-412-032-11 INDUCTOR 100uH
L1001 1-412-032-11 INDUCTOR 100uH
* L1002 1-481-103-21 INDUCTOR 4.7uH (UX71F/UX81F/UX91F)
* L1005 1-481-102-21 INDUCTOR 10uH
L1006 1-481-537-21 INDUCTOR 2.2uH (UX71F/UX81F/UX91F)
* L1007 1-481-103-21 INDUCTOR 4.7uH (UX71F/UX81F/UX91F)
L1008 1-218-953-11 METAL CHIP 1K 5% 1/16W
(UX71F/UX81F/UX91F)
L2000 1-456-499-11 COIL, CHOKE 4.7uH
L2001 1-456-499-11 COIL, CHOKE 4.7uH
L2002 1-481-535-11 INDUCTOR 4.7uH (EXCEPT LA)
< TRANSISTOR >
Q1000 6-552-120-01 FET US6K4TR
Q1002 6-551-346-01 FET LSK3541FS8T2L (UX71F/UX81F/UX91F)
Q1004 6-552-120-01 FET US6K4TR (UX71F/UX81F/UX91F)
Q2001 6-551-202-01 FET LM6K1FS8T2R (EXCEPT LA)
Q2002 6-552-115-01 FET 2SJ0674G0LS0
Q2003 6-551-916-01 FET EM6M1T2R (EXCEPT LA)
Q2005 6-552-124-01 FET RZF030P01TL (EXCEPT LA)
Q2007 6-551-202-01 FET LM6K1FS8T2R
Q2009 6-551-346-01 FET LSK3541FS8T2L
Q2013 6-551-202-01 FET LM6K1FS8T2R
Q2014 6-550-364-01 TRANSISTOR 2SD2652T106
Q2015 6-552-120-01 FET US6K4TR
Q2016 6-552-115-01 FET 2SJ0674G0LS0 (UX71F/UX81F/UX91F)
Q2017 6-552-122-01 FET RUF025N02TL (EXCEPT LA)
Q2018 6-552-122-01 FET RUF025N02TL
Q2019 6-551-346-01 FET LSK3541FS8T2L (EXCEPT LA)
Q4002 6-551-925-01 FET INK0002AT2-T111A-1
Q4003 6-550-239-01 TRANSISTOR DTA144EMFS6T2L
Q4004 6-551-202-01 FET LM6K1FS8T2R
< RESISTOR >
R1000 1-218-990-81 SHORT CHIP 0
R1001 1-218-990-81 SHORT CHIP 0
R1002 1-218-990-81 SHORT CHIP 0
R1003 1-218-985-11 METAL CHIP 470K 5% 1/16W
R1004 1-218-985-11 METAL CHIP 470K 5% 1/16W
R1005 1-218-985-11 METAL CHIP 470K 5% 1/16W
R1006 1-218-977-11 METAL CHIP 100K 5% 1/16W
AUDIO
