Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ICD-UX71/UX71F/UX81/UX81F/UX91F
3939
C5038 1-164-840-11 CERAMIC CHIP 1PF 0.25PF 50V
C6000 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6001 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C7000 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7001 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7002 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C8000 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8001 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8002 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8003 1-100-966-11 CERAMIC CHIP 10uF 20% 10V
C8004 1-112-717-11 CERAMIC CHIP 1uF 10% 6.3V
C8013 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8014 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8015 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN8001 1-820-426-11 CONNECTOR, USB 4P (USB)
CN8002 1-817-951-21 CONNECTOR, BOARD TO BOARD 60P
< DIODE >
D8001 6-501-400-01 DIODE RB161VA-20
D8002 6-501-983-01 DIODE CDZT2R12B
< FILTER >
FL5001 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC5000 6-713-360-01 IC PST8209UL
IC5001 (Not supplied) IC LC823403B-08B-E
IC5002 6-713-490-01 IC PST8227UL
IC5003 6-713-521-01 IC XC6213B152GR
IC6000 (Not supplied) IC M29W160ET70ZA6E
IC7000 (Not supplied) IC K9LBG08U0M-PCB0T (UX91F)
IC7000 (Not supplied) IC K9GAG08U0M-PCB0T (UX81/UX81F)
IC7000 (Not supplied) IC HY27UT088G2A-TPCBDR (UX71/UX71F)
IC8000 6-713-489-01 IC MM3271FURE
IC8001 6-713-505-01 IC XC6221B102NR
< COIL >
L5002
1-481-408-21 INDUCTOR 220nH
LF8001 1-457-223-11 COIL, COMMON MODE CHOKE
< TRANSISTOR >
Q5001 6-551-346-01 FET LSK3541FS8T2L
Q5002 6-551-346-01 FET LSK3541FS8T2L
Q5004 6-551-346-01 FET LSK3541FS8T2L
Q5005 6-552-115-01 FET 2SJ0674G0LS0 (EXCEPT LA)
< RESISTOR >
R5000 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5002 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
(EXCEPT LA)
R5003 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R5006 1-208-663-11 METAL CHIP 150 0.5% 1/16W
R5008 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5011 1-218-969-11 METAL CHIP 22K 5% 1/16W
R5012 1-218-990-81 SHORT CHIP 0
R5014 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5017 1-208-663-11 METAL CHIP 150 0.5% 1/16W
R5018 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5020 1-218-929-11 METAL CHIP 10 5% 1/16W
R5021 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5024 1-218-949-11 METAL CHIP 470 5% 1/16W
R5025 1-218-929-11 METAL CHIP 10 5% 1/16W
R5026 1-218-929-11 METAL CHIP 10 5% 1/16W
R5028 1-218-949-11 METAL CHIP 470 5% 1/16W
R5030 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5034 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5038 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5039 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5040 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5041 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5048 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5066 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5070 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5071 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5072 1-218-990-81 SHORT CHIP 0
R5075 1-218-990-81 SHORT CHIP 0
R6000 1-218-989-11 METAL CHIP 1M 5% 1/16W
R6001 1-218-989-11 METAL CHIP 1M 5% 1/16W
R6002 1-218-989-11 METAL CHIP 1M 5% 1/16W
R6003 1-218-989-11 METAL CHIP 1M 5% 1/16W
R7001 1-218-985-11 METAL CHIP 470K 5% 1/16W
R7011 1-218-985-11 METAL CHIP 470K 5% 1/16W
R7012 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8000 1-218-989-11 METAL CHIP 1M 5% 1/16W
R8001 1-218-989-11 METAL CHIP 1M 5% 1/16W
R8020 1-218-989-11 METAL CHIP 1M 5% 1/16W
< NETWORK RESISTOR >
RB5001 1-234-383-21 RES, NETWORK 470KX4 (1005)
RB7001 1-234-383-21 RES, NETWORK 470KX4 (1005)
RB7002 1-234-383-21 RES, NETWORK 470KX4 (1005)
RB7003 1-234-383-21 RES, NETWORK 470KX4 (1005)
< SWITCH >
S8000 1-771-449-11 SWITCH, SLIDE (DPC)
S8001 1-572-922-11 SWITCH, SLIDE (HOLD)
< THERMISTOR >
TH5000 1-805-194-21 THERMISTOR, NTC (SMD) (EXCEPT LA)
< VIBRATOR >
X5000 1-814-216-11 VIBRATOR, CRYSTAL (12MHz)
*************************************************************
MISCELLANEOUS
**************
J1001 1-822-040-31 JACK (i)
J1002 1-822-040-21 JACK (m)
LCD901 1-802-574-21 DISPLAY PANEL, LIQUID CRYSTAL
MIC902 1-542-785-11 MICROPHONE, ELECTRET CELECTRET (L-CH)
MIC903 1-542-785-11 MICROPHONE, ELECTRET CELECTRET (R-CH)
SP901 1-858-154-11 LOUD SPEAKER (1cm)
*************************************************************
MAIN
When IC5001, IC6000 and IC7000 on the Main board are damaged,
exchange the new Main board for the Main board which IC damaged.
