Sony ICF-22 - SPECIFICATIONS AND FEATURES; TECHNICAL SPECIFICATIONS; SAFETY WARNINGS

Frequency range
Antennas
Speaker
Power output
Output
’ Power requirements
Battery life
Dimensions
Weight
MICROFILM
SPECIFICATIONS
FM: 87.6—107 MHz (for European countries)
87.6—108 MHz (for the United Kingdom)
MW: 530—1,605 kHz (566—187'm) .
LW: 150—255 kHz (2,000—1,176 m)
FM: Telescopic antenna
MW/LW: Built-in ferrite bar antenna
Approx. 7.7 cm (3 inches) dia.
200 mW (at 10 % harmonic distortion)
Earphone jack (minijack)
4.5 V dc, three batteries, IEC designation R6
(size AA) :
DC IN 4.5 V jack accepts:
Approx. 35 hours with Sony SUM-3(NS) New
Super batteries
Approx. 194 x 92 x 34 mm (w/h/d)
(734x 35g x 1% inches)
ing projecting parts and controls wit
includ
ad .
carrying handle pushed in
Approx. 460g (1 Ib 1 oz), including batteries
UK Model
FEATURES
@ High selectivity and high sensitivity with one chip IC
(Integrated Circuit). |
@* Fast tuning to key stations marked on the MW and LW
dial scales for the ICF-25L.
e Two different power sources: batteries and house current.
SAFETY-RELATED COMPONENT WARNING!! -
COMPONENTS IDENTIFIED BY SHADING AND MARK
/A\ ON THE SCHEMATIC DIAGRAMS AND IN THE
PARTS LIST ARE‘ CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
~FM/MW/LW
3 BAND RECEIVER
ON Y.
é
J/oe/ Tbs
