40
ICF-CDK70
SECTION 8
ELECTRICAL PARTS LIST
A-1224-478-A AMP BOARD, COMPLETE
********************
3-254-151-01 SCREW (B2.6), (+) P TAPPING
< CAPACITOR >
C117 1-126-960-11 ELECT 1uF 20% 50V
C119 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C122 1-126-960-11 ELECT 1uF 20% 50V
C123 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C125 1-126-947-11 ELECT 47uF 20% 35V
C126 1-104-665-11 ELECT 100uF 20% 25V
C127 1-126-926-11 ELECT 1000uF 20% 10V
C128 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C217 1-126-960-11 ELECT 1uF 20% 50V
C219 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C222 1-126-960-11 ELECT 1uF 20% 50V
C223 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C225 1-126-947-11 ELECT 47uF 20% 35V
C226 1-104-665-11 ELECT 100uF 20% 25V
C227 1-126-926-11 ELECT 1000uF 20% 10V
C228 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C307 1-104-665-11 ELECT 100uF 20% 25V
C309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C310 1-126-947-11 ELECT 47uF 20% 35V
C311 1-126-935-11 ELECT 470uF 20% 16V
C316 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C318 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C950 1-126-937-11 ELECT 4700uF 20% 16V
C951 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C952 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C953 1-126-935-11 ELECT 470uF 20% 16V
C954 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C956 1-104-665-11 ELECT 100uF 20% 25V
C957 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C959 1-126-934-11 ELECT 220uF 20% 16V
< CONNECTOR >
CN301 1-784-775-11 CONNECTOR, FFC 14P
CN303 1-815-445-11 PIN, CONNECTOR (PWB) 4P
CN903 1-815-443-11 PIN, CONNECTOR (PWB) 2P
< DIODE >
D950 8-719-978-33 DIODE DTZ-TT11-6.8B
D952 8-719-404-50 DIODE MA111-TX
D953 6-500-334-01 DIODE MC2836-T112-1
< IC >
IC302 6-710-261-01 IC UTC8227 S
< TRANSISTOR >
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q202 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q301 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q302 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q950 8-729-018-99 TRANSISTOR 2SD2394-F
Q951 8-729-027-26 TRANSISTOR DTA114YKA-T146
Q952 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q953 8-729-018-99 TRANSISTOR 2SD2394-F
< RESISTOR >
R119 1-216-821-11 METAL CHIP 1K 5% 1/10W
R120 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R121 1-216-837-11 METAL CHIP 22K 5% 1/10W
R122 1-216-809-11 METAL CHIP 100 5% 1/10W
R124 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R125 1-216-849-11 METAL CHIP 220K 5% 1/10W
R126 1-216-864-11 SHORT CHIP 0
R127 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R128 1-216-821-11 METAL CHIP 1K 5% 1/10W
R129 1-216-809-11 METAL CHIP 100 5% 1/10W
R130 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R219 1-216-821-11 METAL CHIP 1K 5% 1/10W
R220 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R221 1-216-837-11 METAL CHIP 22K 5% 1/10W
R222 1-216-809-11 METAL CHIP 100 5% 1/10W
R224 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R225 1-216-849-11 METAL CHIP 220K 5% 1/10W
R226 1-216-864-11 SHORT CHIP 0
R227 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R228 1-216-821-11 METAL CHIP 1K 5% 1/10W
R229 1-216-809-11 METAL CHIP 100 5% 1/10W
R230 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R309 1-216-817-11 METAL CHIP 470 5% 1/10W
R313 1-216-833-11 METAL CHIP 10K 5% 1/10W
R314 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R950 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R951 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R952 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R953 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R954 1-216-833-11 METAL CHIP 10K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . , uPA. . , µPA. . ,
uPB. . : µPB. . , uPC. . , µPC. . ,
uPD. . : µPD. .
• Abbreviation
CND : Canadian model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifi é.
