Sony ICF-CDK70 - Optical Pick-Up Block (KSM-213 CCP)

ICF-CDK70
9
3-7. OPTICAL PICK-UP BLOCK (KSM-213CCP)
 two floating screws (PTPWHM 2.6)
 two floating screws (PTPWHM 2.6)
 two coil springs (insulator)
 two insulators
 two coil springs (insulator)
 two insulators
 Remove soldering from
the four points.
 flexible flat cable (16 core)
(CNP701)
R CD board
RB optical pick-up block
(KSM-213CCP)
mechanism deck
(back side)
 screw
(BVTT2 s 6)
