Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ICF-CDK70
42
LCD
R713 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R714 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R715 1-216-845-11 METAL CHIP 100K 5% 1/10W
R716 1-216-853-11 METAL CHIP 470K 5% 1/10W
R718 1-216-841-11 METAL CHIP 47K 5% 1/10W
R719 1-216-841-11 METAL CHIP 47K 5% 1/10W
R720 1-216-864-11 SHORT CHIP 0
R721 1-216-821-11 METAL CHIP 1K 5% 1/10W
R722 1-216-813-11 METAL CHIP 220 5% 1/10W
R723 1-216-841-11 METAL CHIP 47K 5% 1/10W
R724 1-216-845-11 METAL CHIP 100K 5% 1/10W
R725 1-216-841-11 METAL CHIP 47K 5% 1/10W
R726 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R727 1-216-813-11 METAL CHIP 220 5% 1/10W
R728 1-216-837-11 METAL CHIP 22K 5% 1/10W
R729 1-216-837-11 METAL CHIP 22K 5% 1/10W
R730 1-216-845-11 METAL CHIP 100K 5% 1/10W
R731 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R732 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R733 1-216-837-11 METAL CHIP 22K 5% 1/10W
R734 1-216-841-11 METAL CHIP 47K 5% 1/10W
R735 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R736 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R737 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R738 1-216-809-11 METAL CHIP 100 5% 1/10W
R739 1-216-809-11 METAL CHIP 100 5% 1/10W
R740 1-216-809-11 METAL CHIP 100 5% 1/10W
R741 1-216-809-11 METAL CHIP 100 5% 1/10W
R742 1-216-809-11 METAL CHIP 100 5% 1/10W
R743 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R744 1-216-809-11 METAL CHIP 100 5% 1/10W
R745 1-216-864-11 SHORT CHIP 0
R746 1-216-837-11 METAL CHIP 22K 5% 1/10W
R747 1-216-817-11 METAL CHIP 470 5% 1/10W
R748 1-216-853-11 METAL CHIP 470K 5% 1/10W
R749 1-216-817-11 METAL CHIP 470 5% 1/10W
R750 1-216-817-11 METAL CHIP 470 5% 1/10W
R751 1-216-817-11 METAL CHIP 470 5% 1/10W
R752 1-216-817-11 METAL CHIP 470 5% 1/10W
R753 1-216-841-11 METAL CHIP 47K 5% 1/10W
R754 1-216-841-11 METAL CHIP 47K 5% 1/10W
R755 1-216-841-11 METAL CHIP 47K 5% 1/10W
R756 1-216-837-11 METAL CHIP 22K 5% 1/10W
R757 1-216-841-11 METAL CHIP 47K 5% 1/10W
R758 1-216-833-11 METAL CHIP 10K 5% 1/10W
R760 1-216-821-11 METAL CHIP 1K 5% 1/10W
R761 1-216-821-11 METAL CHIP 1K 5% 1/10W
R762 1-216-837-11 METAL CHIP 22K 5% 1/10W
R763 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R764 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R765 1-216-821-11 METAL CHIP 1K 5% 1/10W
R766 1-216-841-11 METAL CHIP 47K 5% 1/10W
R767 1-216-817-11 METAL CHIP 470 5% 1/10W
R768 1-216-813-11 METAL CHIP 220 5% 1/10W
R769 1-216-833-11 METAL CHIP 10K 5% 1/10W
R770 1-216-821-11 METAL CHIP 1K 5% 1/10W
R771 1-216-849-11 METAL CHIP 220K 5% 1/10W
R773 1-216-833-11 METAL CHIP 10K 5% 1/10W
R774 1-216-837-11 METAL CHIP 22K 5% 1/10W
R775 1-216-833-11 METAL CHIP 10K 5% 1/10W
R776 1-216-833-11 METAL CHIP 10K 5% 1/10W
R777 1-216-833-11 METAL CHIP 10K 5% 1/10W
R778 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
S701 1-572-085-21 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X701 1-795-563-21 VIBRATOR, CERAMIC (16.9344MHz)
************************************************************
A-1224-512-A JACK BOARD, COMPLETE
********************
< CAPACITOR >
C107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C207 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< FERRITE BEAD >
FB101 1-414-445-11 FERRITE, EMI (SMD) (1608)
FB201 1-414-445-11 FERRITE, EMI (SMD) (1608)
FB301 1-414-445-11 FERRITE, EMI (SMD) (1608)
< JACK >
J301 1-566-822-51 JACK (AUDIO IN)
************************************************************
A-1224-508-A KEY BOARD, COMPLETE
*******************
< RESISTOR >
R401 1-216-813-11 METAL CHIP 220 5% 1/10W
R402 1-216-817-11 METAL CHIP 470 5% 1/10W
R403 1-216-821-11 METAL CHIP 1K 5% 1/10W
R404 1-216-821-11 METAL CHIP 1K 5% 1/10W
R408 1-216-813-11 METAL CHIP 220 5% 1/10W
R409 1-216-817-11 METAL CHIP 470 5% 1/10W
R410 1-216-821-11 METAL CHIP 1K 5% 1/10W
R411 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S402 1-786-050-21 SWITCH, KEY BOARD
(., TUNER/PRESET/TRACK –)
S403 1-786-050-21 SWITCH, KEY BOARD
(EX-CHANGE, TUNING MODE)
S404 1-786-050-21 SWITCH, KEY BOARD (OPEN/CLOSE, Z)
S406 1-786-050-21 SWITCH, KEY BOARD
(>, TUNER/PRESET/TRACK +)
S407 1-786-050-21 SWITCH, KEY BOARD
(RADIO/BAND, AUTO PRESET)
S408 1-786-050-21 SWITCH, KEY BOARD (OFF, x)
S409 1-786-050-21 SWITCH, KEY BOARD (CD u)
************************************************************
A-1224-496-A LCD BOARD, COMPLETE
********************
2-893-495-01 PLATE (LCD), LIGHT GUIDE
2-893-506-01 CASE (LCD), SHIELD
2-893-522-01 HOLDER (LCD)
2-896-914-01 SHEET, DIFFUSION
KEYJACKCD
