Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ICF-CDK70
46
R828 1-216-864-11 SHORT CHIP 0
R829 1-216-833-11 METAL CHIP 10K 5% 1/10W
R830 1-216-833-11 METAL CHIP 10K 5% 1/10W
R831 1-216-864-11 SHORT CHIP 0
R832 1-216-833-11 METAL CHIP 10K 5% 1/10W
R833 1-216-833-11 METAL CHIP 10K 5% 1/10W
R834 1-216-864-11 SHORT CHIP 0
R835 1-216-833-11 METAL CHIP 10K 5% 1/10W
R836 1-216-833-11 METAL CHIP 10K 5% 1/10W
R839 1-216-821-11 METAL CHIP 1K 5% 1/10W
R840 1-216-833-11 METAL CHIP 10K 5% 1/10W
R842 1-216-833-11 METAL CHIP 10K 5% 1/10W
R844 1-216-833-11 METAL CHIP 10K 5% 1/10W
R846 1-216-821-11 METAL CHIP 1K 5% 1/10W
R847 1-216-849-11 METAL CHIP 220K 5% 1/10W
R848 1-216-821-11 METAL CHIP 1K 5% 1/10W
R849 1-216-833-11 METAL CHIP 10K 5% 1/10W
R850 1-216-821-11 METAL CHIP 1K 5% 1/10W
R851 1-216-833-11 METAL CHIP 10K 5% 1/10W
R852 1-216-864-11 SHORT CHIP 0
R853 1-216-864-11 SHORT CHIP 0
R854 1-216-864-11 SHORT CHIP 0
R855 1-216-821-11 METAL CHIP 1K 5% 1/10W
R856 1-216-821-11 METAL CHIP 1K 5% 1/10W
R857 1-216-841-11 METAL CHIP 47K 5% 1/10W
R858 1-216-821-11 METAL CHIP 1K 5% 1/10W
R859 1-216-821-11 METAL CHIP 1K 5% 1/10W
R860 1-216-821-11 METAL CHIP 1K 5% 1/10W
R863 1-216-821-11 METAL CHIP 1K 5% 1/10W
R864 1-216-833-11 METAL CHIP 10K 5% 1/10W
R865 1-216-821-11 METAL CHIP 1K 5% 1/10W
R866 1-216-833-11 METAL CHIP 10K 5% 1/10W
R867 1-216-821-11 METAL CHIP 1K 5% 1/10W
R870 1-216-821-11 METAL CHIP 1K 5% 1/10W
R872 1-216-833-11 METAL CHIP 10K 5% 1/10W
R874 1-216-833-11 METAL CHIP 10K 5% 1/10W
R875 1-216-833-11 METAL CHIP 10K 5% 1/10W
R876 1-216-821-11 METAL CHIP 1K 5% 1/10W
R878 1-216-821-11 METAL CHIP 1K 5% 1/10W
R879 1-216-821-11 METAL CHIP 1K 5% 1/10W
R880 1-216-821-11 METAL CHIP 1K 5% 1/10W
R881 1-216-821-11 METAL CHIP 1K 5% 1/10W
R882 1-216-864-11 SHORT CHIP 0
R883 1-216-821-11 METAL CHIP 1K 5% 1/10W
R884 1-216-821-11 METAL CHIP 1K 5% 1/10W
R885 1-216-817-11 METAL CHIP 470 5% 1/10W
R886 1-216-817-11 METAL CHIP 470 5% 1/10W
R887 1-216-821-11 METAL CHIP 1K 5% 1/10W
R888 1-216-821-11 METAL CHIP 1K 5% 1/10W
R895 1-216-837-11 METAL CHIP 22K 5% 1/10W
R897 1-216-837-11 METAL CHIP 22K 5% 1/10W
R963 1-216-817-11 METAL CHIP 470 5% 1/10W
R964 1-216-821-11 METAL CHIP 1K 5% 1/10W
R965 1-216-805-11 METAL CHIP 47 5% 1/10W
R966 1-216-833-11 METAL CHIP 10K 5% 1/10W
R969 1-216-797-11 METAL CHIP 10 5% 1/10W
< VIBRATOR >
X801 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
X802 1-813-175-21 VIBRATOR, CERAMIC (4.19MHz)
************************************************************
A-1224-514-A MEGA BASS BOARD, COMPLETE
**************************
< SWITCH >
S401 1-786-050-21 SWITCH, KEY BOARD (AUDIO IN)
S417 1-771-905-21 SWITCH, SLIDE (MEGA BASS)
************************************************************
A-1224-482-A POWER BOARD, COMPLETE (US)
A-1225-192-A POWER BOARD, COMPLETE (CND)
***********************
< CAPACITOR >
C901 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C902 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C903 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C904 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C907 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C908 1-126-947-11 ELECT 47uF 20% 35V
C909 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN902 1-815-443-11 PIN, CONNECTOR (PWB) 2P
CN904 1-815-443-21 PIN, CONNECTOR (PWB) 2P
< DIODE >
D901 6-501-582-01 DIODE 1N4002-B5
D902 6-501-582-01 DIODE 1N4002-B5
D903 6-501-582-01 DIODE 1N4002-B5
D904 6-501-582-01 DIODE 1N4002-B5
< FUSE HOLDER >
FH901 1-533-233-31 FUSE HOLDER (CND)
FH902 1-533-233-31 FUSE HOLDER (CND)
< COIL >
L901 1-402-964-11 COIL, AIR-CORE
L902 1-402-964-11 COIL, AIR-CORE
************************************************************
A-1224-499-A REMOTE CONTROL BOARD, COMPLETE
********************************
< CAPACITOR >
C408 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< LED >
D406 8-719-059-97 LED L-34HD (TIMER)
< IC >
IC401 6-600-349-21 IC NJL23H400A
< RESISTOR >
R428 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
REMOTE CONTROLPOWERMEGA BASSMAIN
Ver. 1.1
To Next Page
