3-3. MECHANISM DECK (DLM3A23-11)
(When TRAY carries out movable.)
 two claws

 cover (tray)
 Close the tray.
 two screws (B2.6)
 two screws (B2.6)
 flexible flat cable (14 co
r
(CN801)
 Lift up the mechanism deck (DLM3
A
in the direction of an arrow.
R mechanism deck
(DLM3A23-11)
 flexible flat cable (13 core)
(CN305)
 Press the OPEN/CLOSE button
to open the tray.
