146
Color Background
No.
Parameter
Adjustment
3
Hue
Hue
No.
Parameter
Adjustment
1
Luminance
Luminance
2
Saturation
Saturation
Chapter
8
Color
Backgrounds,
Copy
and
Swap,
and
Other
Settings
Color Backgrounds, Copy
and Swap, and Other Settings
Chapter
8
Color Background
The dedicated generators generate color signals, and these
can be used as color backgrounds in video effects.
Color background selection
There are two color backgrounds, color background 1 and
color background 2, which you use by assigning to cross-
point buttons.
Color mix
The color generators can output the result of combining
two colors (color 1 and color 2).
Using a pattern from a dedicated pattern generator, color 1
and color 2 can be combined in the boundary region,
forming a color gradation. This is referred to as “color mix.”
You can also apply modifiers to the selected pattern.
When the color mix function is not used, the result is a flat
color, and color 1 is always output.
You carry out color background settings in the Color Bkgd
menu.
This section describes settings for color background 1 as
an example.
Basic Color Background Setting
Operations
Setting a single-color matte (Flat Color)
If you are not using the color mix function to combine two
colors, use the following procedure.
1 In the Color Bkgd >Color Bkgd1 menu (2210), press
[Flat Color] in the <Matte> group, turning it on.
2 Set the following parameters.
Setting a color mix
To combine color 1 and color 2, use the following
procedure.
1 In the Color Bkgd >Color Bkgd1 menu (2210), press
[Mix Color] in the <Matte> group, turning it on.
2 Set the following parameters.
No.
Parameter
Adjustment
1
Size
Pattern size
2
Soft
Edge softness of the pattern
5
Pattern
Pattern number
a)
a) The patterns are the same as for a wipe ( 1 “Wipe Pattern List”
(p. 381)).
For the pattern selection, you can also press [Mix
Pattern Select] in the Color Bkgd1 menu, then use the
Mix Ptn Select menu (2210.1).
Press the desired pattern (1 to 24) to select it, and set
the Size and Soft parameters.
3 To adjust colors 1 and 2, turn on [Color1] or [Color2]
respectively, then adjust the following parameters.
No.
Parameter
Adjustment
1
Luminance
Luminance
2
Saturation
Saturation
3
Hue
Hue
4 If required, set the pattern modifiers.
When turning [Position] on and setting the pattern
position
No.
Parameter
Adjustment
1
Position H
Horizontal position
a)
2
Position V
Vertical position
a)
a) 1 p. 103.
