System Settings
Carry out operations relating to setup for the whole system
in the Engineering Setup >System menu.
Here the “whole system” refers to all devices connected on
the system switcher LAN.
Setting the unit ID
If an MVE-8000A or MVE-9000 is connected to an MVS-
6520/6530/3000A/3000, the unit ID must be set to 2.
In addition, the switcher processor, DME (MKS-6570),
and control panel are all tied to unit ID of 1.
For more details of how to make the unit ID settings, refer
to the installation manual for the particular device.
Notes
The MVS-3000 does not support the MKS-6570 DME
board.
Network Settings
This provides automatic configuration of all devices
connected to the switcher system LAN, and displays a list
of them.
Setting the Group ID
1
In the Engineering Setup >System >Network Config
menu (7311), press [Group ID].
2
Enter a number (1 to 8) in the pop-up menu, and press
[Enter].
3
Check the message, then press [Yes].
Authenticating the IP Address
Automatically
1
In the Engineering Setup >System >Network Config
menu (7311), press [Auto Config].
2
Check the message, then press [Yes].
Devices with the same group ID within the network
are detected and displayed.
3
To register the list of detected devices as the setting
values at power-on, press [Define].
4
Check the message, then press [Yes].
Setting the Signal Format
Notes
After changing any of the following settings, be sure to
press [Execute] (or [FC Format Execute] for changing the
format converter signal format) to save the new values.
When you press [Execute], some data is lost (such as frame
memory images).
If you press [FC Format Execute], this data is not lost.
Setting the Signal Format
Specify the signal format to be handled by the devices.
The combinations of signal formats that can be selected are
as follows.
Notes
The DME1 signal format is in common with the switcher.
