Copy and Swap 147
No.
Parameter
Adjustment
1
H Multi
Number of repetitions of pattern
horizontally
2
V Multi
Number of repetitions of pattern
vertically
3
Invert Type
a)
Target bank
Target data
M/E-1
PGM/PST
Bank settings excluding the following
data items:
• Setup data
• Snapshots
• Keyframe effects
• Key snapshots
• Key memory
No.
Parameter
Adjustment
1
Amplitude
Amplitude of modulation
2
Frequency
Frequency of modulation
3
Speed
Speed of waves
• Negative values create waves
in the down, left, and
counterclockwise directions.
• Positive values create waves in
the up, right, and clockwise
directions.
Chapter
8
Color
Backgrounds,
Copy
and
Swap,
and
Other
Settings
When turning [Multi] on and using replications of
the same pattern
5 To interchange color 1 and color 2, press the [Color
Invert] button, turning it on.
Copy and Swap
a) 1 p. 105.
Replication layout
Overview of Copy and Swap
When turning [Aspect] on and setting the aspect
ratio of the pattern
No.
Parameter
Adjustment
1
Aspect
Aspect ratio
a)
a) 1 p. 105.
When turning [Pairing] on and making a wipe
pattern like a Venetian blind
No.
Parameter
Adjustment
1
Width
Width
When turning [Angle] on in the <Rotation> group
and slanting the pattern
No.
Parameter
Adjustment
1
Angle
Rotation angle of pattern
a)
a) 1 p. 104.
When turning [Speed] on in the <Rotation> group
and rotating the pattern at a constant rate
No.
Parameter
Adjustment
1
Speed
Rotation speed of pattern
a)
a) 1 p. 104.
When selecting [H] (horizontal) or [V] (vertical) in
the <Modulation> group and applying waviness to
the pattern
You can copy or swap the settings among the switcher
banks or between keyers.
The following settings can be copied or swapped.
• Overall settings for the M/E and PGM/PST banks
• Keyer settings
• Wipe settings in a transition control block
• Independent key wipe settings in a transition control
block
• DME wipe settings in a transition control block
• Independent key DME wipe settings in a transition
control block
• Matte color settings (color 1, color 2, and how to
compose them)
• Color settings
• DME channel settings
• Format converter input settings (copy only)
• Format converter output settings (copy only)
You can carry out keyer copy operations by a simple
button operation.
M/E copy and M/E swap
You can copy and swap the overall bank settings among
the switcher banks.
Notes
When using 1080PsF mode in an HD system, the
modulation function is not available.
Notes
If a DME is being used on the source M/E bank, then if for
example there are insufficient DME channels, it may not
be possible to select the DME.
There are no such restrictions on a swap.
Keyer copy and keyer swap
You can carry out copy and swap operations among the
following keyers.
