Don't curve FPC parts mounted
area. If it is curved, the solder
point on FPC may get damaged.
Don’t touch FPC parts mounted
area when assembling.
Pull lightly FPC in the direction of the figure below red.
FPC is rotated and unlocking hook.
118
