Sony KD-55A9F - No Power DDCON;LDO

(Supplementary
information)
1.3 No Power DDCON/LDO
Check item summary
22
BM3/ DPJ Board OLED Model
Board IC Ref Voltage supply Output ref. Enable pin Enable source Fuse Vcc ref.
BM3 IC400 1.2V_HDMI C434 R417 P-on u-com IC800 #pin13 - C433
BM3 IC402 5V_MAIN/5V_AUDIO C430 R455 P-on u-com IC800 #pin13 F400 C423
BM3 IC403 3.3V_MAIN/3.3V_AUDIO C419 R409 P-on u-com IC800 #pin13 F401 C418
BM3 IC405 1.8V_TU C463 IC405 #PIN5 P-on u-com IC800 #pin13 F403 C461
BM3 IC601 1.2V_M3_DDR C609 C607 R605 (3.3V_STBY) - C603
BM3 IC602 1.05V_M3_STBY C611 C610 C610 (3.3V _STBY) - C610
BM3 IC603 1.05V_M3_ST_ET C613 R614 M3 IC1000 #AJ11 - C612
BM3 IC604 1.05V_M3_A C616 IC604 #PIN5 P-on u-com IC800 #pin13 F603 C615
BM3 IC606 2.5V_M3_DDR C619 C618 C618 (3.3V_STBY) - C618
BM3 IC607 1.8V_EMMC C622 C677 R616 (DDR_EMMC_EN ) - C620
BM3 IC608 1.0V_M3_CORE C634 R634 P-on u-com IC800 #pin12 F600 C623
BM3 IC609 1.0V_M3_CPU C648 R644 P-on u-com IC800 #pin12 F601 C639
BM3 IC610 1.0V_M3_GPU C662 R654 P-on u-com IC800 #pin12 F602 C653
pin12 : P_ON_#1
pin13 : P_ON_#2
