1.3 No Power DDCON/LDO
Check item summary
23
BM3/ DPJ Board OLED Model
Board IC Ref Voltage supply Output ref. Enable pin Enable source Fuse Vcc ref.
DPJ IC804 3.3V_MAIN C817 R810
P-on u-com IC800 #pin13
CN5601 #pin 17
F800 C816
DPJ IC6600
1.8V_BE
C6601
R6601
(No mount / shorted)
P-on u-com IC800 #pin13
CN5601 #pin 17
- C6600
DPJ IC6601 1.5V_BE_DDR C6606 IC6601 #PIN5
P-on u-com IC800 #pin13
CN5601 #pin 17
F6600 C6605
DPJ IC6602 0.9V_BE C6637 R6609
P-on u-com IC800 #pin12
CN5601 #pin 18
F6603 C6636
DPJ IC6604 0.8V_BE C6624 R6634
P-on u-com IC800 #pin12
CN5601 #pin 18
F6602 C6617
P-on u-com IC800 is on BM3 board.
pin12 : P_ON_#1
pin13 : P_ON_#2
