Sony KDL-40V3000 User Manual

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 91 -
G3
* A-1268-619-A G3 COMPLETE
4-382-854-11 SCREW (M3X10), P, SW (+)
< CAPACITOR >
C6000 1-113-889-11 CERAMIC 0.001UF 20.00% 250V
C6002 £ 1-165-530-11 MYLAR 0.47UF 10 275V
C6005 1-113-889-11 CERAMIC 0.001UF 20.00% 250V
C6006 £ 1-114-153-11 CERAMIC 680PF 10% 250V
C6007 £ 1-119-892-51 CERAMIC 470PF 10.00% 250V
C6010 £ 1-114-153-11 CERAMIC 680PF 10% 250V
C6011 £ 1-119-892-51 CERAMIC 470PF 10.00% 250V
C6012 £ 1-165-529-11 MYLAR 0.22UF 10 275V
C6014 £ 1-161-964-91 CERAMIC 0.0047UF 250V
C6015 £ 1-161-964-91 CERAMIC 0.0047UF 250V
C6016 1-114-379-21 ELECT(BLOCK) 150UF 20% 450V
C6017 1-114-379-21 ELECT(BLOCK) 150UF 20% 450V
C6018 1-119-894-51 CERAMIC 2200PF 20.00% 250V
C6019 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C6020 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C6100 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6101 1-100-831-91 CERAMIC CHIP 0.001UF 2% 50V
C6102 1-107-906-11 ELECT 10UF 20% 50V
C6103 1-107-905-11 ELECT 4.7UF 20% 50V
C6104 1-107-910-11 ELECT 100UF 20% 50V
C6106 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6107 1-107-888-11 ELECT 47UF 20% 25V
C6108 1-115-340-11 CERAMIC CHIP 0.22UF 10.00% 25V
C6110 1-112-481-11 CERAMIC 470PF 10% 1KV
C6111 1-100-310-11 FILM 18000PF 3% 800V
C6112 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C6150 1-104-760-11 CERAMIC CHIP 0.047UF 10.00% 50V
C6152 1-112-231-21 ELECT 2200UF 20% 16V
C6154 1-112-835-11 ELECT 3300UF 20% 25V
C6157 1-112-231-21 ELECT 2200UF 20% 16V
C6160 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6170 1-112-231-21 ELECT 2200UF 20% 16V
C6200 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6201 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C6202 1-107-903-11 ELECT 2.2UF 20% 50V
C6203 1-100-139-31 FILM 0.001UF 5% 630V
C6204 1-107-904-11 ELECT 3.3UF 20% 50V
C6205 1-107-910-11 ELECT 100UF 20% 50V
C6206 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6250 1-128-949-31 ELECT 470UF 20% 16V
C6251 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6300 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C6301 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6302 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6304 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V
C6305 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6306 1-125-891-11 CERAMIC CHIP 0.47UF 10.00% 10V
C6307 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6308 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V
C6309 1-107-910-11 ELECT 100UF 20% 50V
C6310 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6311 1-131-872-91 CERAMIC CHIP 1000PF 10% 630V
C6402 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6403 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6408 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C6410 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C6411 1-125-891-11 CERAMIC CHIP 0.47UF 10.00% 10V
C6500 1-112-744-61 MYLAR 1UF 10% 450V
C6501 1-112-188-11 MYLAR 1.5UF 5% 450V
C6503 1-112-188-11 MYLAR 1.5UF 5% 450V
C6505 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6506 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C6507 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C6508 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V
C6510 1-107-902-11 ELECT 1UF 20% 50V
C6511 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C6512 1-162-959-11 CERAMIC CHIP 330PF 5.00% 50V
C6513 1-112-481-11 CERAMIC 470PF 10% 1KV
C6514 1-112-481-11 CERAMIC 470PF 10% 1KV
C6515 1-112-481-11 CERAMIC 470PF 10% 1KV
C6516 1-112-481-11 CERAMIC 470PF 10% 1KV
C6517 1-100-566-91 CERAMIC CHIP 0.1UF 10.00% 25V
C6518 1-107-908-11 ELECT 33UF 20% 50V
C6519 1-107-906-11 ELECT 10UF 20% 50V
C6521 1-107-906-11 ELECT 10UF 20% 50V
< CONNECTOR >
CN6000 £ * 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
CN6001 1-695-915-11 TAB (CONTACT)
CN6002 1-695-915-11 TAB (CONTACT)
CN6003 1-695-915-11 TAB (CONTACT)
CN6202 * 1-785-708-11 PIN, CONNECTOR (PC BOARD) 12P
CN6203 1-785-707-11 PIN, CONNECTOR (PC BOARD) 11P
CN6204 * 1-778-853-11 PIN, CONNECTOR (PC BOARD) 8P
CN6501 * 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
CN6502 * 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D6000 8-719-054-89 DIODE D15XB60
D6100 8-719-081-67 DIODE M1FM3
D6101 6-500-137-01 DIODE BAT54HT1
D6102 8-719-017-89 DIODE MA8150-TX
D6104 8-719-979-64 DIODE UF4005/23
D6105 8-719-081-67 DIODE M1FM3
D6151 8-719-060-88 DIODE D4SBS6

Sony KDL-40V3000 Specifications

General

Audio system	B/G, D/K, I, L, NICAM
RMS rated power	20 W
Sound output mode	3
Noise reduction	Yes
Comb filter	Digital
Response time	8 ms
Display diagonal	40 \
Display brightness	500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (dynamic)	16000:1
Contrast ratio (typical)	1800:1
Tuner type	Analog & digital
Supported TV bands	CATV, UHF, VHF
Analog signal format system	PAL, SECAM
AV input	RCA
SCART ports quantity	2
Digital audio optical out	1
Picture enhancement	BRAVIA ENGINE
Headphone connectivity	3.5 mm
Cables included	AC
Remote control type	RM-ED009
Product color	Black
Power consumption (standby)	0.3 W
Power consumption (typical)	169 W

Weight and Dimensions

Depth (with stand)	265 mm
Width (with stand)	992 mm
Height (with stand)	688 mm
Weight (with stand)	24000 g
Depth (without stand)	122 mm
Height (without stand)	643 mm
Weight (without stand)	20000 g
