Sony KDL-40V3000 User Manual

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 92 -
D1 G3
D6152 6-501-545-01 DIODE SG10SC6-F5
D6153 6-501-545-01 DIODE SG10SC6-F5
D6201 8-719-058-74 DIODE 05NU42-TPA2
D6203 6-500-567-31 DIODE 10ERB20-TB3
D6204 6-500-567-31 DIODE 10ERB20-TB3
D6206 8-719-404-50 DIODE MA111-TX
D6250 8-719-510-02 DIODE D1NS4
D6251 8-719-073-35 DIODE RB551V-30TE-17
D6303 8-719-404-50 DIODE MA111-TX
D6304 8-719-404-50 DIODE MA111-TX
D6308 8-719-404-50 DIODE MA111-TX
D6309 8-719-404-50 DIODE MA111-TX
D6310 8-719-404-50 DIODE MA111-TX
D6311 8-719-018-01 DIODE MA8220-TX
D6312 8-719-058-74 DIODE 05NU42-TPA2
D6313 8-719-404-50 DIODE MA111-TX
D6400 8-719-017-89 DIODE MA8150-TX
D6401 8-719-404-50 DIODE MA111-TX
D6402 8-719-404-50 DIODE MA111-TX
D6404 8-719-404-50 DIODE MA111-TX
D6500 £ 6-500-108-01 DIODE EP05FA20
D6501 £ 6-500-108-01 DIODE EP05FA20
D6502 6-500-137-01 DIODE BAT54HT1
D6503 8-719-404-50 DIODE MA111-TX
D6506 6-501-871-01 DIODE MA2DF60001S0
D6511 8-719-404-50 DIODE MA111-TX
D6512 8-719-404-50 DIODE MA111-TX
D6513 6-500-137-01 DIODE BAT54HT1
ET6000 1-537-770-21 TERMINAL BOARD, GROUND
ET6001 1-537-770-21 TERMINAL BOARD, GROUND
ET6002 1-537-770-21 TERMINAL BOARD, GROUND
ET6003 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE >
F6000 £ 1-576-233-51 FUSE 6.3A 250V
FH6000 £ 1-533-223-11 FUSE HOLDER 7.5A 250V
FH6001 £ 1-533-223-11 FUSE HOLDER 7.5A 250V
< FERRITE BEAD >
FB6000 1-412-911-11 FERRITE 0UH
FB6001 1-412-911-11 FERRITE 0UH
FB6004 1-410-396-41 FERRITE 0.45UH
FB6005 1-410-396-41 FERRITE 0.45UH
FB6100 1-412-911-11 FERRITE 0UH
FB6101 1-412-911-11 FERRITE 0UH
FB6150 1-412-911-11 FERRITE 0UH
FB6151 1-412-911-11 FERRITE 0UH
FB6152 1-412-911-11 FERRITE 0UH
FB6153 1-412-911-11 FERRITE 0UH
< IC >
IC6100 6-707-749-01 IC CXD9841P
IC6150 6-709-368-01 IC MM1431ATT (CN)
IC6200 6-708-801-01 IC MIP2H2
IC6250 6-709-442-01 IC MM1530ATT
IC6300 6-709-368-01 IC MM1431ATT (CN)
IC6301 6-709-368-01 IC MM1431ATT (CN)
IC6500 6-709-791-01 IC L6562N
< COIL >
L6000 £ 1-457-457-11 LINE FILTER COIL
L6002 £ 1-457-457-11 LINE FILTER COIL
L6150 1-414-487-41 INDUCTOR 1UH
L6151 1-414-487-41 INDUCTOR 1UH
L6152 1-457-239-11 INDUCTOR 4.7UH
L6250 1-414-183-41 INDUCTOR 10UH
L6500 1-457-277-11 INDUCTOR 260UH
L6501 1-457-435-11 INDUCTOR 300UH
< PHOTOCOUPLER >
PH6100 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
PH6200 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
PH6300 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
PH6301 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
PH6302 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
< TRANSISTOR >
Q6100 6-551-302-01 TRANSISTOR 2SK3561(LBS1SONY,Q
Q6101 6-551-302-01 TRANSISTOR 2SK3561(LBS1SONY,Q
Q6300 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q6301 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6303 6-551-678-01 TRANSISTOR 2SA1364-T111-1DE
Q6304 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6305 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6306 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6307 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q6403 6-551-714-01 TRANSISTOR INK0001AC1-T112A-1
Q6405 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q6406 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6407 6-551-714-01 TRANSISTOR INK0001AC1-T112A-1
Q6500 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q6501 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q6502 6-551-336-01 TRANSISTOR 2SK3934(LBS1SONY.Q
Q6503 6-551-336-01 TRANSISTOR 2SK3934(LBS1SONY.Q
Q6504 8-729-820-90 TRANSISTOR 2SD1621-ST
Q6505 8-729-804-41 TRANSISTOR 2SB1122-S
Q6506 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF

Sony KDL-40V3000 Specifications

General

Audio system	B/G, D/K, I, L, NICAM
RMS rated power	20 W
Sound output mode	3
Noise reduction	Yes
Comb filter	Digital
Response time	8 ms
Display diagonal	40 \
Display brightness	500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (dynamic)	16000:1
Contrast ratio (typical)	1800:1
Tuner type	Analog & digital
Supported TV bands	CATV, UHF, VHF
Analog signal format system	PAL, SECAM
AV input	RCA
SCART ports quantity	2
Digital audio optical out	1
Picture enhancement	BRAVIA ENGINE
Headphone connectivity	3.5 mm
Cables included	AC
Remote control type	RM-ED009
Product color	Black
Power consumption (standby)	0.3 W
Power consumption (typical)	169 W

Weight and Dimensions

Depth (with stand)	265 mm
Width (with stand)	992 mm
Height (with stand)	688 mm
Weight (with stand)	24000 g
Depth (without stand)	122 mm
Height (without stand)	643 mm
Weight (without stand)	20000 g
