100
KF-42E200A/42E201A/50E200A/50E201A
KF-42E200A/42E201A/50E200A/50E201A
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
FUSE
!
F6000 1-532-506-32 FUSE 6.3A 250V
FERRITE BEAD
FB6000 1-410-396-41 FERRITE 0.45µH
FB6001 1-410-396-41 FERRITE 0.45µH
FB6002 1-410-396-41 FERRITE 0.45µH
FB6003 1-412-911-11 FERRITE 0µH
FB6004 1-412-911-11 FERRITE 0µH
FB6800 1-414-921-11 FERRITE 0µH
IC
!
IC6000 6-705-810-01 IC MCZ3001DB
!
IC6001 6-709-499-01 IC RT9H301C-T112-1
IC6002 8-759-701-56 IC NJM78M05FA
IC6003 6-705-466-01 IC BA90BC0T
IC6007 6-708-388-01 IC KA278RA05CYDTU
IC6500 6-705-464-01 IC BA50BC0T
IC6800 6-708-659-01 IC BA00BC0WT-V5
IC6801 6-706-740-01 IC BA00BC0WFP-E2
IC6802 6-706-740-01 IC BA00BC0WFP-E2
IC6803 6-706-740-01 IC BA00BC0WFP-E2
IC6804 8-752-072-94 IC CXA1875AM-T4
COIL
L6000 1-406-659-11 INDUCTOR 10µH
L6007 1-412-519-11 INDUCTOR 3.3µH
L6008 1-412-519-11 INDUCTOR 3.3µH
L6009 1-406-983-11 INDUCTOR 1MH
L6010 1-412-521-31 INDUCTOR 4.7µH
!
L6011 1-456-859-21 LINE FILTER COIL
!
L6012 1-456-859-21 LINE FILTER COIL
L6015 1-406-657-11 INDUCTOR 4.7µH
L6016 1-412-525-31 INDUCTOR 10µH
L6800 1-416-511-11 INDUCTOR 47µH
L6900 1-414-856-11 INDUCTOR 10µH
PHOTO COUPLER
!
PH6001 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
!
PH6003 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
TRANSISTOR
!
Q6001 6-550-882-01 TRANSISTOR 2SK3568(LBS2SONY,Q
Q6003 8-729-600-22 TRANSISTOR 2SA1235-F
Q6004 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6007 8-729-120-28 TRANSISTOR 2SC1623-L5L6
!
Q6008 6-550-882-01 TRANSISTOR 2SK3568(LBS2SONY,Q
Q6500 8-729-600-22 TRANSISTOR 2SA1235-F
Q6800 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6803 8-729-600-22 TRANSISTOR 2SA1235-F
Q6804 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6805 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6806 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6807 8-729-600-22 TRANSISTOR 2SA1235-F
Q6808 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6809 8-729-600-22 TRANSISTOR 2SA1235-F
Q6810 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6811 8-729-600-22 TRANSISTOR 2SA1235-F
Q6812 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6813 8-729-600-22 TRANSISTOR 2SA1235-F
RESISTOR
R6002 1-215-904-11 METAL OXIDE 100K 5% 2W
R6003 1-215-904-11 METAL OXIDE 100K 5% 2W
R6005 1-216-864-11 SHORT CHIP
R6006 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
R6007 1-218-855-11 METAL CHIP 2.2K 0.50% 1/10W
R6009 1-218-863-11 METAL CHIP 4.7K 0.50% 1/10W
R6010 1-216-864-11 SHORT CHIP
R6011 1-216-864-11 SHORT CHIP
R6016 1-202-933-61 FUSIBLE 0.1 10% 1/2W
R6017 1-249-377-11 CARBON 0.47 5% 1/4W
R6018 1-249-377-11 CARBON 0.47 5% 1/4W
R6019 1-218-823-11 METAL CHIP 100 0.50% 1/10W
R6020 1-218-870-11 METAL CHIP 9.1K 0.50% 1/10W
R6029 1-245-472-21 METAL 270K 1% 1/4W
R6030 1-245-471-21 METAL 240K 1% 1/4W
R6031 1-245-471-21 METAL 240K 1% 1/4W
R6032 1-245-471-21 METAL 240K 1% 1/4W
R6035 1-218-877-11 METAL CHIP 18K 0.50% 1/10W
R6042 1-211-991-11 METAL CHIP 82 0.50% 1/10W
R6043 1-212-897-00 FUSIBLE 470 5% 1/4W
