KF-42E200A/42E201A/50E200A/50E201A
KF-42E200A/42E201A/50E200A/50E201A
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
HB
A-1177-120-A HB BOARD, MOUNTED
CAPACITOR
C110 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C111 1-128-991-21 ELECT CHIP 10µF 20% 50V
C112 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C113 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C114 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C115 1-165-908-11 CERAMIC CHIP 1µF 10% 10V
C116 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
C117 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
C118 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C119 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C120 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C121 1-162-974-11 CERAMIC CHIP 0.01µF 50V
CONNECTOR
* CN110 1-820-292-11 HEADER ASSEMBLY (PRINT PWB) 13P
DIODE
D113 6-500-861-01 DIODE SML-020MVT-T86
D114 8-719-064-07 DIODE SML-310LTT86
D115 6-500-861-01 DIODE SML-020MVT-T86
IC
IC110 6-707-223-01 IC LM75BIM-5/NOPB
IC111 6-703-744-01 IC GP1UE26SXKOF
TRANSISTOR
Q110 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q111 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q112 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q113 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R110 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R112 1-216-801-11 METAL CHIP 22 5% 1/10W
R113 1-216-805-11 METAL CHIP 47 5% 1/10W
R114 1-216-864-11 SHORT CHIP
R115 1-216-801-11 METAL CHIP 22 5% 1/10W
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-833-11 METAL CHIP 10K 5% 1/10W
R119 1-216-864-11 SHORT CHIP
R122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R123 1-216-833-11 METAL CHIP 10K 5% 1/10W
R124 1-216-813-11 METAL CHIP 220 5% 1/10W
R125 1-216-813-11 METAL CHIP 220 5% 1/10W
R126 1-216-833-11 METAL CHIP 10K 5% 1/10W
R127 1-216-833-11 METAL CHIP 10K 5% 1/10W
R128 1-216-813-11 METAL CHIP 220 5% 1/10W
R129 1-216-833-11 METAL CHIP 10K 5% 1/10W
R130 1-216-833-11 METAL CHIP 10K 5% 1/10W
R131 1-216-833-11 METAL CHIP 10K 5% 1/10W
R132 1-216-833-11 METAL CHIP 10K 5% 1/10W
R133 1-218-839-11 METAL CHIP 470 0.50% 1/10W
R137 1-218-839-11 METAL CHIP 470 0.50% 1/10W
R138 1-216-864-11 SHORT CHIP
SWITCH
S110 1-692-431-21 SWITCH, TACTILE
HC
A-1161-597-A HC BOARD, MOUNTED
CAPACITOR
C181 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C182 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C183 1-124-779-00 ELECT CHIP 10µF 20% 16V
C184 1-124-779-00 ELECT CHIP 10µF 20% 16V
CONNECTOR
* CN180 1-820-189-11 HEADER ASSEMBLY (PRINT PWB) 12P
DIODE
D180 8-719-977-28 DIODE DTZ10B
D181 8-719-977-28 DIODE DTZ10B
D183 8-719-083-58 DIODE UDZSTE-173.9B
JACK
J180 1-819-355-21 PHONO JACK 3P
J181 1-819-356-21 PHONO JACK 3P
HB HC
