KF-42E200A/42E201A/50E200A/50E201A
KF-42E200A/42E201A/50E200A/50E201A
31
SPEAKER GRILL WIRE DRESSING (CONTINUED)
Dress HA/HB Connector Assy to Wire holder as shown above.
When routing HA/HB Connector Assy through Wire Holder
“RED” tape should be approximately in the position shown
above.
To Next Page
