Sony KF-42E200A - Page 80

80
KF-42E200A/42E201A/50E200A/50E201A
KF-42E200A/42E201A/50E200A/50E201A
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
A
FB1005 1-414-226-21 FERRITE 0µH
FB1006 1-414-226-21 FERRITE 0µH
FB1007 1-414-226-21 FERRITE 0µH
FB1008 1-414-226-21 FERRITE 0µH
FB1009 1-414-226-21 FERRITE 0µH
IC
IC1000 8-749-925-00 IC TK11819MTL
IC1001 6-708-171-01 IC MIC5235YM5TR
COIL
L1000 1-400-180-21 FERRITE 0µH
L1001 1-414-755-11 INDUCTOR 22µH
L1002 1-412-642-61 INDUCTOR 1.2MH
L1003 1-414-755-11 INDUCTOR 22µH
L1004 1-414-754-11 INDUCTOR 10µH
L1005 1-414-754-11 INDUCTOR 10µH
L1006 1-414-754-11 INDUCTOR 10µH
L1007 1-414-754-11 INDUCTOR 10µH
TRANSISTOR
Q1000 8-729-600-22 TRANSISTOR 2SA1235-F
Q1001 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1002 8-729-600-22 TRANSISTOR 2SA1235-F
Q1003 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1004 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R1003 1-216-864-11 SHORT CHIP
R1004 1-216-864-11 SHORT CHIP
R1005 1-216-864-11 SHORT CHIP
R1006 1-216-864-11 SHORT CHIP
R1007 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1008 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1009 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1010 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1011 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1012 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1013 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1014 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1015 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1016 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1017 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1018 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1019 1-216-295-91 SHORT CHIP
R1021 1-216-809-11 METAL CHIP 100 5% 1/10W
R1022 1-218-911-11 METAL CHIP 470K 0.50% 1/10W
R1023 1-218-891-11 METAL CHIP 68K 0.50% 1/10W
R1024 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R1025 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1030 1-218-895-11 METAL CHIP 100K 0.50% 1/10W
R1031 1-216-864-11 SHORT CHIP
R1032 1-216-809-11 METAL CHIP 100 5% 1/10W
R1033 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1034 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1038 1-216-809-11 METAL CHIP 100 5% 1/10W
R1039 1-216-864-11 SHORT CHIP
R1041 1-216-809-11 METAL CHIP 100 5% 1/10W
R1042 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1043 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1044 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1045 1-216-817-11 METAL CHIP 470 5% 1/10W
R1047 1-216-833-11 METAL CHIP 10K 5% 1/10W
TUNER
TU1000 8-597-561-00 TUNER, FSS BTF-CA401Z
B2
A-1220-317-A B2 BLOCK ASSEMBLY
Due to the complexity of this board, performing component level fi eld repairs is not
recommended. If service is required, complete block assembly replacement is the
preferred repair method. Data is provided for reference only.
CAPACITOR
C2000 1-127-931-21 ELECT CHIP 470µF 20% 16V
C2005 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C2006 1-124-779-00 ELECT CHIP 10µF 20% 16V
C2007 1-124-779-00 ELECT CHIP 10µF 20% 16V
C2008 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C2009 1-128-996-11 ELECT CHIP 4.7µF 20% 50V
C2010 1-115-416-11 CERAMIC CHIP 0.001µF 5% 25V
C2011 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
C2012 1-128-357-11 ELECT CHIP 10µF 20% 16V
C2013 1-128-357-11 ELECT CHIP 10µF 20% 16V
B2
