Sony KV-21FA210 TRINITRON - Page 48

— 48 —
KV-21FA210
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
D044 8-719-110-17 DIODE RD10ESB2
D045 8-719-110-17 DIODE RD10ESB2
D050 8-719-991-33 DIODE 1SS133T-77
D051 8-719-991-33 DIODE 1SS133T-77
D052 8-719-109-89 DIODE RD5.6ESB2
D200 8-719-929-15 DIODE HZS9.1NB2
D201 8-719-929-15 DIODE HZS9.1NB2
D202 8-719-929-15 DIODE HZS9.1NB2
D203 8-719-929-15 DIODE HZS9.1NB2
D204 8-719-929-15 DIODE HZS9.1NB2
D205 8-719-929-15 DIODE HZS9.1NB2
D206 8-719-929-15 DIODE HZS9.1NB2
D208 8-719-929-15 DIODE HZS9.1NB2
D230 8-719-108-12 DIODE RD9.1EW
D231 8-719-108-12 DIODE RD9.1EW
D232 8-719-108-12 DIODE RD9.1EW
D234 8-719-108-12 DIODE RD9.1EW
D235 8-719-108-12 DIODE RD9.1EW
D236 8-719-108-12 DIODE RD9.1EW
D237 8-719-108-12 DIODE RD9.1EW
D351 8-719-109-66 DIODE RD3.3ESB2
D390 8-719-404-50 DIODE MA111-TX
D410 8-719-404-50 DIODE MA111-TX
D412 1-216-864-11 SHORT CHIP
D413 8-719-404-50 DIODE MA111-TX
D414 8-719-921-63 DIODE MTZJ-7.5B
D435 8-719-110-17 DIODE RD10ESB2
D438 8-719-404-50 DIODE MA111-TX
D501 8-719-404-50 DIODE MA111-TX
D505 8-719-081-00 DIODE BY228/A52A/
D506 8-719-979-85 DIODE EGP20G
D508 8-719-404-50 DIODE MA111-TX
D509 8-719-109-66 DIODE RD3.3ESB2
D514 8-719-908-03 DIODE GP08D
D515 8-719-908-03 DIODE GP08D
D525 8-719-991-33 DIODE 1SS133T-77
D526 8-719-074-25 DIODE PG104R
D528 8-719-991-33 DIODE 1SS133T-77
D545 8-719-908-03 DIODE GP08D
D558 8-719-404-50 DIODE MA111-TX
D559 8-719-404-50 DIODE MA111-TX
! D562 8-719-991-33 DIODE 1SS133T-77
! D566 8-719-979-84 DIODE EGP20DPKG23
! D567 8-719-991-33 DIODE 1SS133T-77
D568 8-719-110-08 DIODE RD8.2ESB2
! D569 8-719-921-44 DIODE MTZJ-5.1C
D587 8-719-074-25 DIODE PG104R
! D589 8-719-991-33 DIODE 1SS133T-77
D596 8-719-908-03 DIODE GP08D
D598 8-719-908-03 DIODE GP08D
D605 6-500-397-11 DIODE GBJ4J10B9
D608 8-719-077-76 DIODE D2SB60A-F04
D611 8-719-302-43 DIODE EL1Z
D612 8-719-068-00 DIODE ERC04-06SE
(LATIN NORTH ONLY)
D613 8-719-068-00 DIODE ERC04-06SE
(LATIN NORTH ONLY)
D614 8-719-057-52 DIODE EZ0150AV1
D615 6-500-177-01 DIODE MA7D50
D618 8-719-979-64 DIODE UF4005PKG23
D620 8-719-911-19 DIODE 1SS119-25
D621 8-719-510-37 DIODE D5LC20U
D624 8-719-302-43 DIODE EL1Z
D628 8-719-404-50 DIODE MA111-TX
D629 8-719-110-31 DIODE RD12ESB2
D630 8-719-982-22 DIODE MTZJ-30D
D631 6-500-175-01 DIODE 1E3-TB
D650 8-719-109-89 DIODE RD5.6ESB2
FUSE
! F601 1-532-506-51 FUSE 6.3A 250V
(LATIN SOUTH ONLY)
! F601 1-576-193-11 FUSE 6.3A 125V
(LATIN NORTH ONLY)
FERRITE BEAD
FB461 1-410-397-21 FERRITE 1.1µH
FB462 1-410-397-21 FERRITE 1.1µH
FB463 1-410-397-21 FERRITE 1.1µH
FB464 1-410-397-21 FERRITE 1.1µH
FB465 1-410-397-21 FERRITE 1.1µH
FB466 1-410-397-21 FERRITE 1.1µH
FB467 1-410-397-21 FERRITE 1.1µH
FB468 1-410-397-21 FERRITE 1.1µH
FB505 1-410-397-21 FERRITE 1.1µH
FB506 1-410-397-21 FERRITE 1.1µH
A
