Sony KV-21FA210 TRINITRON - Page 49

— 49 —
KV-21FA210
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
FB522 1-410-397-21 FERRITE 1.1µH
FB601 1-412-911-11 FERRITE 0µH
FB602 1-412-911-11 FERRITE 0µH
FB603 1-412-911-11 FERRITE 0µH
FB604 1-412-911-11 FERRITE 0µH
FB605 1-576-337-21 IC LINK 2.7A 50V
FB616 1-469-578-11 FERRITE 1.1µH
FB617 1-469-578-11 FERRITE 1.1µH
FB669 1-410-397-21 FERRITE 1.1µH
FB670 1-410-397-21 FERRITE 1.1µH
FB671 1-410-397-21 FERRITE 1.1µH
FB672 1-410-397-21 FERRITE 1.1µH
FILTER
FL001 1-239-803-11 ENCAPSULATED COMPONENT
IC
! IC001 6-800-842-01 IC M65582µF-100FP
IC002 8-759-699-33 IC M24C16-MN6T(A)
IC003 8-759-352-91 IC PST9143NL
IC400 6-703-190-01 IC NJW1134AGK1-TE2
IC545 8-759-835-98 IC AN5522
! IC561 8-759-700-07 IC NJM2903M
IC565 8-759-700-44 IC NJM2902M
IC600 8-759-670-30 IC MCZ3001D
IC603 8-759-833-71 IC NJM2395F09
! IC604 8-749-012-13 IC DM-58
IC608 6-701-752-01 IC NJM2930F05B
IC633 6-703-080-01 IC LF33CV
JACK
J200 1-794-119-11 TERMINAL BLOCK, S 4P
J201 1-794-048-11 JACK, PIN 3P
J202 1-794-116-11 JACK BLOCK, PIN 2P
* J205 1-817-529-11 JACK BLOCK, PIN 4P
J206 1-794-117-11 JACK BLOCK, PIN 3P
J401 1-750-264-11 JACK
CHIP CONDUCTOR
JR1 1-216-864-11 SHORT CHIP
JR6 1-216-864-11 SHORT CHIP
JR7 1-216-864-11 SHORT CHIP
JR12 1-216-864-11 SHORT CHIP
JR20 1-216-864-11 SHORT CHIP
JR44 1-216-864-11 SHORT CHIP
JR003 1-216-864-11 SHORT CHIP
JR004 1-216-864-11 SHORT CHIP
JR128 1-216-864-11 SHORT CHIP
JR200 1-216-864-11 SHORT CHIP
JR301 1-216-864-11 SHORT CHIP
JR302 1-216-864-11 SHORT CHIP
JR303 1-216-864-11 SHORT CHIP
JR304 1-216-864-11 SHORT CHIP
JR305 1-216-864-11 SHORT CHIP
JR306 1-216-864-11 SHORT CHIP
JR307 1-216-864-11 SHORT CHIP
JR308 1-216-864-11 SHORT CHIP
JR309 1-216-864-11 SHORT CHIP
JR310 1-216-864-11 SHORT CHIP
JR311 1-216-864-11 SHORT CHIP
JR312 1-216-864-11 SHORT CHIP
JR313 1-216-864-11 SHORT CHIP
JR314 1-216-864-11 SHORT CHIP
JR315 1-216-864-11 SHORT CHIP
JR316 1-216-864-11 SHORT CHIP
JR317 1-216-864-11 SHORT CHIP
JR318 1-216-864-11 SHORT CHIP
JR401 1-216-864-11 SHORT CHIP
JR485 1-216-864-11 SHORT CHIP
JR500 1-216-864-11 SHORT CHIP
JR501 1-216-864-11 SHORT CHIP
JR502 1-216-864-11 SHORT CHIP
JR860 1-216-864-11 SHORT CHIP
JUMPER WIRE
JW68 1-249-417-11 CARBON 1K 5% 1/4W
JW491 1-249-429-11 CARBON 10K 5% 1/4W
A
