Sony KV-21FE13 - Adjustment Items

— 17 —
KV-21FE13 / 21FE13C / 21FM13 / 21FM13C
ADJUSTMENT ITEMS (1 OF 2)
Reg # ITEM FUNCTION RANGE
FIX
DATA NTSC VIDEO RF
AVERAGE
DATA
1 HSIZ Horizontal Size Adjustment 0-63 35 38
2 HPOS Horizontal Position Adjustment 0-63 33 21
3 VBOW Vertical Line Bowing Adj. 0-15 5 9
4 VANG Vertical line Bowing Slant Adj. 0-15 7 7
5 TRAP Horizontal Trapezoid Adj. 0-15 7 7
6 PAMP Horizontal PIN Distortion Adj. 0-63 7 32
7 UPIN Upper PIN Distortion Adj. 0-63 36 39
8 LPIN Lower PIN Distortion Adj. 0-63 36 39
9 VM Velocity Modulation On/Off 0,1 0
10 BLKO Vertical Blanking On/Off 0,1 0 0
11 VMLV Velocity Modulation Level 0-3 2
12 AGN2 Aging 2 0,1 0 0
13 REFP Reference Pulse Position 0,1 0 0
14 VBLK Vertical Blanking On/Off 0,1 0 0
15 JPSW 0,1 0 0
16 VSIZ Vertical Size Adjustment 0-63 40 49
17 VPOS Vertical Position Adj. 0-63 32 32
18 VLIN Vertical Linearity Adj. 0-15 7 6
19 SCOR Vertical "S" Correction Adjustment 0-15 6 8
20 VZOM 16:9 CRT Z Mode On/Off 0,1 0 0
21 EHT Vertical High-Voltage Correction 0-15 15 6
22 ASP Aspect Ratio Control 0-63 47 47
23 SCRL 16:9 CRT Z Mode Trans. Scroll 0-63 31 31
24 HBLK Horizontal Blanking On/Off 0,1 1 1
25 LBLK Left Blanking Adjustment 0-15 11 12
26 RBLK Right Blanking Adjustment 0-15 8 5
27 VUSN V Saw Waveform Compress 0,1 0 0
28 HDW Horizontal Drive Pulse Width 0,1 1 1
29 EWDC "Parabola" EW/ D.C. Adjustment 0.1 0 0
30 LVLN Lower Screen BTM Vertical Line Adj. 0-15 0 0
31 UVLN Upper Screen BTM Vertical Line Adj. 0-15 0 0
32 HTRP Horizontal Trapezoid Adj. 0,1 0 0
33 RDRV R Output Drive Control 0-63 31 36
34 GDRV G Output Drive Control 0-63 21 26
35 BDRV B Output Drive Control 0-63 21 25
36 RCUT R Output Cutoff Control 0-15 10 8
37 GCUT G Output Cutoff Control 0-15 6 6
38 BCUT B Output Cutoff Control 0-15 6 7
39 DCOL Dynamic Color On/Off 0,1 0 1
40 SHUE Sub HUE 0-31 12 15
41 SCOL Sub Color 0-31 14 15
42 SBRT Sub BRIGHTNESS 0-31 13 15
43 RON R Output On/Off 0,1 1 1
44 GON G Output On/Off 0,1 1 1
45 BON B Output On/Off 0,1 1 1
46 AXPL Axis PAL 0,1 0 0
47 AXNT Axis NTSC 0,1 0 0
48 CBPF Chroma BPF On/Off 0,1 1 1
49 CTRP Y TRAP FILTER On/Off 0,1 1 1
50 COFF Color On/Off 0,1 0 0
51 KOFF Set Color Killer 0,1 0 0
52 SSHP Sub SHARPNESS 0-15 5 7
Palette mode controls this register
Palette mode controls this register
