— 39 —
KV-21FE13 / 21FE13C / 21FM13 / 21FM13C
SECTION 7: ELECTRICAL PARTS LIST
*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonfl ammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF.NO. PART NO. DESCRIPTION VALUES
The components in this manual identifi ed by the following
symbol:
X
indicate parts that have been carefully factory-
selected to satisfy regulations regarding X-ray radiation for
each set.
Should replacement be required for one of these
components, replace only with the value originally used.
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
NOTE: Les composants identifi es par un trame et
une marque
!
sont critiques pour la securite. Ne
les remplacer que par une piece portant le numero
specifi e.
When ordering parts by reference
number, please include the board name.
A
REF.NO. PART NO. DESCRIPTION VALUES
* A-1299-182-A A COMPLETE PC BOARD
(KV-21FE13 ONLY)
* A-1299-174-A A COMPLETE PC BOARD
(KV-21FE13C ONLY)
* A-1299-518-A A COMPLETE PC BOARD
(KV-21FM13 ONLY)
* A-1299-189-A A COMPLETE PC BOARD
(KV-21FM13C ONLY)
The high-voltage leads associated with the FBT on the A board are not
included and must be ordered separately. Order the following leads when
requesting this A board:
!
1-251-642-52 HV CAP ASSY
!
1-900-800-65 FOCUS LEAD
!
1-900-803-22 G2 LEAD
* 1-508-784-21 PIN,CONNECTOR (5MM PITCH) 1P
1-533-223-11 HOLDER, FUSE
* 4-374-846-11 COVER,CAPACITOR, CAP TYPE
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C100 1-164-346-11 CERAMIC CHIP 1µF 16V
C101 1-164-346-11 CERAMIC CHIP 1µF 16V
C102 1-126-933-11 ELECT 100µF 20% 16V
C104 1-126-941-11 ELECT 470µF 20% 25V
C105 1-104-664-11 ELECT 47µF 20% 25V
C204 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C205 1-126-963-11 ELECT 4.7µF 20% 50V
C207 1-126-963-11 ELECT 4.7µF 20% 50V
(KV-21FE13/21FE13C ONLY)
C208 1-126-963-11 ELECT 4.7µF 20% 50V
C210 1-126-963-11 ELECT 4.7µF 20% 50V
(KV-21FE13/21FE13C ONLY)
C214 1-164-346-11 CERAMIC CHIP 1µF 16V
C215 1-164-346-11 CERAMIC CHIP 1µF 16V
(KV-21FE13/21FE13C ONLY)
C216 1-126-963-11 ELECT 4.7µF 20% 50V
C219 1-126-964-11 ELECT 10µF 20% 50V
C402 1-126-943-11 ELECT 2200µF 20% 25V
C403 1-126-957-11 ELECT 0.22µF 20% 50V
C420 1-164-222-91 CERAMIC CHIP 0.22µF 25V
C421 1-164-222-91 CERAMIC CHIP 0.22µF 25V
C438 1-126-940-11 ELECT 330µF 20% 25V
C439 1-126-940-11 ELECT 330µF 20% 25V
C442 1-126-963-11 ELECT 4.7µF 20% 50V
C444 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C448 1-164-222-91 CERAMIC CHIP 0.22µF 25V
(KV-21FE13/21FE13C/21FM13 ONLY)
C454 1-164-222-91 CERAMIC CHIP 0.22µF 25V
(KV-21FE13/21FE13C/21FM13 ONLY)
C496 1-216-295-91 SHORT
C501 1-102-112-00 CERAMIC 330pF 10% 50V
C502 1-106-383-00 MYLAR 0.047µF 10% 200V
C503 1-102-212-00 CERAMIC 820pF 10% 500V
C504 1-102-002-00 CERAMIC 680pF 10% 500V
!
C505 1-162-134-11 CERAMIC 470pF 10% 2KV
C506 1-162-318-11 CERAMIC 0.001µF 10% 500V
!
C507 1-117-642-11 FILM 8200pF 3% 1.2KV
C508 1-137-150-11 MYLAR 0.01µF 10% 100V
!
C509 1-162-116-00 CERAMIC 680pF 10% 2KV
C510 1-107-651-11 ELECT 4.7µF 20% 250V
!
C511 1-115-519-11 FILM 0.56µF 5% 250V
!
C512 1-106-383-00 MYLAR 0.047µF 10% 200V
C513 1-104-987-11 MYLAR 0.001µF 10% 100V
!
C514 1-115-521-11 FILM 0.82µF 5% 250V
!
C515 1-162-116-00 CERAMIC 680pF 10% 2KV
C516 1-117-214-11 CERAMIC 0.001µF 10% 2KV
!
C520 1-129-722-00 FILM 0.047µF 5% 630V
C521 1-164-646-11 CERAMIC 2200pF 10% 500V
C523 1-126-941-11 ELECT 470µF 20% 25V
C524 1-102-244-00 CERAMIC 220pF 10% 500V
C525 1-162-815-11 CERAMIC 47pF 5% 500V
C526 1-126-960-11 ELECT 1µF 20% 50V
C527 1-126-965-91 ELECT 22µF 20% 50V
C528 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
