— 49 —
KV-21FE13 / 21FE13C / 21FM13 / 21FM13C
NOTE: The components identifi ed by shading and
! mark are critical for safety. Replace only with
part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque ! sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
CONNECTOR
* CN701 1-564-506-11 PLUG,CONNECTOR 3P
CN702 1-695-915-11 TAB (CONTACT)
CN704 1-785-879-11 CONNECTOR, ONE TOUCH
* CN706 1-564-509-11 PLUG,CONNECTOR 6P
DIODE
D701 8-719-901-83 DIODE 1SS83TD
D702 8-719-901-83 DIODE 1SS83TD
D703 8-719-901-83 DIODE 1SS83TD
D704 8-719-302-43 DIODE RGP10GPKG23
IC
! IC701 8-759-803-42 IC LA6500-FA
IC702 8-759-562-43 IC TDA6108JF/N1B
JACK
! J701 1-451-470-21 SOCKET, CRT
COIL
L701 1-408-613-31 INDUCTOR 68µH
TRANSISTOR
Q700 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q701 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R700 1-249-433-11 CARBON 22K 5% 1/4W
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-249-409-11 CARBON 220 5% 1/4W
R703 1-247-807-31 CARBON 100 5% 1/4W
R704 1-249-421-11 CARBON 2.2K 5% 1/4W
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-249-381-11 CARBON 1 5% 1/4W
R707 1-249-383-11 CARBON 1.5 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R709 1-247-807-31 CARBON 100 5% 1/4W
R710 1-247-807-31 CARBON 100 5% 1/4W
R711 1-260-328-11 CARBON 1K 5% 1/2W
R712 1-260-328-11 CARBON 1K 5% 1/2W
R713 1-260-328-11 CARBON 1K 5% 1/2W
R714 1-260-087-11 CARBON 100 5% 1/2W
R715 1-260-132-11 CARBON 560K 5% 1/2W
R716 1-260-123-11 CARBON 100K 5% 1/2W
R718 1-216-375-00 METAL OXIDE 3.3 5% 2W
R719 1-215-888-00 METAL OXIDE 220 5% 2W
R720 1-249-421-11 CARBON 2.2K 5% 1/4W
R721 1-249-421-11 CARBON 2.2K 5% 1/4W
VARIABLE RESISTOR
RV701 1-241-656-11 RES, ADJ, METAL FILM 110M
VB
* A-1342-537-A VB (VAR) BOARD, MOUNTED
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C901 1-107-667-11 ELECT 2.2µF 20% 160V
C902 1-130-491-00 MYLAR 0.047µF 5% 50V
C903 1-126-935-11 ELECT 470µF 20% 10V
C904 1-130-471-00 MYLAR 0.001µF 5% 50V
C905 1-106-383-00 MYLAR 0.047µF 10% 200V
C906 1-130-471-00 MYLAR 0.001µF 5% 50V
C907 1-107-638-11 ELECT 33µF 20% 160V
C908 1-126-935-11 ELECT 470µF 20% 10V
C909 1-161-830-00 CERAMIC 0.0047µF 500V
C910 1-104-999-11 MYLAR 0.1µF 10% 200V
C911 1-104-665-11 ELECT 100µF 20% 10V
C912 1-126-941-11 ELECT 470µF 20% 25V
C913 1-102-074-00 CERAMIC 0.001µF 10% 50V
C914 1-130-491-00 MYLAR 0.047µF 5% 50V
CONNECTOR
* CN901 1-564-508-11 PLUG,CONNECTOR 5P
CN903 1-564-506-11 PLUG,CONNECTOR 3P
DIODE
D901 8-719-110-88 DIODE MTZJ-T-77-39
D902 8-719-110-88 DIODE MTZJ-T-77-39
D903 8-719-991-33 DIODE 1SS133T-77
TRANSISTOR
Q901 8-729-017-06 TRANSISTOR 2SC4793
Q902 8-729-017-05 TRANSISTOR 2SA1837
Q903 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q904 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q905 8-729-119-76 TRANSISTOR 2SA1309A-QRSTA
Q906 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R901 1-249-401-11 CARBON 47 5% 1/4W
R902 1-249-386-11 CARBON 2.7 5% 1/4W
R903 1-249-414-11 CARBON 560 5% 1/4W
R904 1-249-432-11 CARBON 18K 5% 1/4W
R905 1-249-417-11 CARBON 1K 5% 1/4W
R906 1-249-432-11 CARBON 18K 5% 1/4W
CB
VB
