Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
30
MC-S50
LOGIC POWER
< SWITCH >
S803 1-762-333-21 SWITCH, TACTILE (MODE)
S804 1-762-333-21 SWITCH, TACTILE (Bx)
S805 1-762-333-21 SWITCH, TACTILE (>)
S806 1-762-333-21 SWITCH, TACTILE (.)
S807 1-762-333-21 SWITCH, TACTILE (MEGA BASS/AVLS)
< VARISTOR >
VDR801 1-803-742-21 VARISTOR, CHIP
VDR802 1-803-742-21 VARISTOR, CHIP
VDR803 1-803-742-21 VARISTOR, CHIP
VDR804 1-803-742-21 VARISTOR, CHIP
VDR805 1-803-742-21 VARISTOR, CHIP
< VIBRATOR >
X601 1-781-746-21 VIBRATOR, CRYSTAL (16.9344MHz)
X801 1-767-994-23 VIBRATOR, CRYSTAL (32.768kHz)
X802 1-795-100-21 VIBRATOR, CERAMIC (8MHz)
X901 1-781-620-21 VIBRATOR, CERAMIC (48MHz)
**************************************************************
A-3323-698-A POWER BOARD, COMPLETE
***********************
< CAPACITOR >
C402 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C404 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C406 1-137-763-21 TANTALUM CHIP 33uF 20% 6.3V
C407 1-137-763-21 TANTALUM CHIP 33uF 20% 6.3V
C408 1-137-763-21 TANTALUM CHIP 33uF 20% 6.3V
C409 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C410 1-128-964-11 TANTALUM CHIP 100uF 20% 6.3V
C411 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C412 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C413 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C414 1-137-763-11 TANTALUM CHIP 33uF 20% 6.3V
C415 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C416 1-164-866-11 CERAMIC CHIP 47PF 5% 16V
C417 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C418 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C420 1-128-964-11 TANTALUM CHIP 100uF 20% 6.3V
C421 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C422 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C423 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C424 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C427 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN401 1-815-120-21 CONNECTOR, BOARD TO BOARD 24P
< DIODE >
D401 8-719-056-59 DIODE MAZS120008SO
D402 8-719-071-34 DIODE RB521S-30-TE61
D403 8-719-069-29 DIODE RB520S-30TE61
D405 8-719-069-29 DIODE RB520S-30TE61
D809 8-719-056-59 DIODE MAZS120008SO
D810 8-719-056-59 DIODE MAZS120008SO
< IC >
IC401 8-759-656-52 IC MAX1674EUA-TG069
IC402 8-759-572-21 IC S-80808ANNP-E7Y-T2
IC403 8-759-530-11 IC S-80809ANNP-E7Z-T2
IC404 8-759-713-51 IC MAX1692EUB-TG069
IC405 8-759-676-78 IC MM1320FNLE
IC802 8-759-659-13 IC PST3428UL
< COIL >
L401 1-416-944-21 COIL, CHOKE 15uH
L402 1-414-398-11 INDUCTOR 10uH
L403 1-419-627-21 INDUCTOR 10uH
L404 1-414-398-11 INDUCTOR 10uH
< TRANSISTOR >
Q401 8-729-046-75 TRANSISTOR SI2301DS-T1
Q402 8-729-037-74 TRANSISTOR UN9213J- (K8).SO
Q403 8-729-425-25 TRANSISTOR XN4604-TX
Q405 8-729-425-25 TRANSISTOR XN4604-TX
< RESISTOR >
R402 1-218-970-11 METAL CHIP 27K 0.5% 1/16W
R403 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R404 1-218-990-11 SHORT 0
R405 1-218-878-11 METAL CHIP 20K 0.5% 1/16W
R406 1-218-977-11 RES-CHIP 100K 5% 1/16W
R408 1-218-965-11 RES-CHIP 10K 5% 1/16W
R409 1-218-965-11 RES-CHIP 10K 5% 1/16W
R410 1-218-965-11 RES-CHIP 10K 5% 1/16W
R411 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R412 1-218-980-11 RES-CHIP 180K 5% 1/16W
R414 1-218-990-11 SHORT 0
R415 1-218-892-11 METAL CHIP 75K 0.5% 1/16W
R416 1-208-670-11 METAL CHIP 300K 0.5% 1/16W
R417 1-218-990-11 SHORT 0
R418 1-208-955-11 METAL CHIP 680K 0.5% 1/16W
R419 1-208-947-11 METAL CHIP 330K 0.5% 1/16W
R420 1-218-977-11 RES-CHIP 100K 5% 1/16W
R421 1-218-953-11 RES-CHIP 1K 5% 1/16W
R422 1-218-990-11 SHORT 0
R423 1-218-965-11 RES-CHIP 10K 5% 1/16W
R424 1-218-965-11 RES-CHIP 10K 5% 1/16W
R426 1-208-920-11 METAL CHIP 24K 0.5% 1/16W
R428 1-218-965-11 RES-CHIP 10K 5% 1/16W
R429 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R430 1-218-980-11 RES-CHIP 180K 5% 1/16W
R431 1-218-990-11 SHORT 0
R435 1-218-977-11 RES-CHIP 100K 5% 1/16W
R436 1-218-977-11 RES-CHIP 100K 5% 1/16W
< SWITCH >
S801 1-762-333-21 SWITCH, TACTILE (VOL +)
S802 1-762-333-21 SWITCH, TACTILE (VOL -)
< THERMISTOR (POSITIVE) >
THP401 1-803-870-21 THERMISTOR, POSITIVE
**************************************************************
