Appendix
Appendix A-5
Processor adjustment range
Video level ±3 dB/ –∞ to +3 dB selectable
Chroma level ±3 dB/ –∞ to +3 dB selectable
Setup level (MSW-A2000/2000)
±30 IRE
Black level (MSW-A2000P/M2000P/M2000EP)
±210 mV
Y/C delay ±100 ns (in analog Betacam
playback)
Chroma phase ±30°
System phase Sync: ±15 µs
SC: ±200 ns
Input connectors
SDI INPUT BNC (1 with active through out)
Serial digital (270 Mbits/s)
SMPTE 259M/ITU-R BT.656
SDTI-CP INPUT BNC (1)
SMPTE 326M
REF. VIDEO INPUT
BNC (2 in loop through
connection)
Black burst or composite sync
0.3 Vp-p, 75 Ω, sync negative
COMPONENT VIDEO INPUT
BNC (3 for 1 set)
Y: 1.0 Vp-p, Sync negative
R–Y/B–Y: 0.7 Vp-p, 75 Ω, with
100% color bar for MSW-
A2000P/M2000P/M2000EP and
with 100% or 75% color bar
selectable for MSW-A2000/
M2000/M2000E
COMPOSITE VIDEO INPUT
BNC (2 in loop through
connection)
1.0 Vp-p, 75 Ω, Sync negative
AUDIO INPUT CH1/2/3/4
XLR 3-pin, female (4)
LOW OFF: –60 dBu, high
impedance, balanced
HIGH OFF: +4 dBu, high
impedance, balanced
HIGH ON: +4 dBm, 600 Ω
termination, balanced
AUDIO INPUT(AES/EBU) CH1/2, 3/4, 5/6, 7/8
BNC (4)
Complies with AES-3id-1995
TIME CODE IN XLR 3-pin, female (1)
0.5 to 18 Vp-p, 10 kΩ, balanced
Output connectors
SDI OUTPUT BNC (3 including 1 for character
superimposition)
Serial digital (270 Mbits/ s)
SMPTE 259 M/ITU-R BT.656
SDTI-CP OUTPUT
BNC (2)
SMPTE 326M
COMPONENT VIDEO OUTPUT
BNC (3 for 1 set)
Y: 1.0 Vp-p, Sync negative
R–Y/B–Y: 0.7 Vp-p, 75 Ω, with
100% color bar for MSW-
A2000P/M2000P/M2000EP and
with 100% or 75% color bar
selectable for MSW-A2000/
M2000/M2000E
COMPOSITE VIDEO OUTPUT
BNC (3 including 1 for character
superimposition)
1.0 Vp-p, 75 Ω, Sync negative
AUDIO OUTPUT CH1/2/3/4
XLR 3-pin, male (4)
+4 dBm at 600 Ω load, low
impedance, balanced
AUDIO OUTPUT (AES/EBU) CH1/2, 3/4, 5/6, 7/8
BNC (4)
Complies with AES-3id-1995
MONITOR OUTPUT (L/R)
XLR 3-pin, male (2)
+4 dBm at 600 Ω load, low
impedance, balanced
TIME CODE OUT
XLR 3-pin, male (1)
2.2 Vp-p, low impedance, balanced
PHONES JM-60 stereo phone jack
–∞ to –12 dBu at 8 Ω load,
unbalanced
CUE OUT XLR 3-pin, male
+4 dBm at 600 Ω load, low
impedance, balanced (MSW-
M2000/M2000P/M2000EP only)
