Sony mxp-29 - Page 74

PGA
Ref.
No.
SP
Pact
No.
Description
C362
S
1-123-379-00
CAP,
ELECT 0.47 20%
100V
C363
S
1-123-306-00
CAP,
ELECT 47
20% 10V
C364
S
1-123-332-00
CAP, ELECT 47
20% 25V
C365
S
1-123-332-00
CAP, ELECT 47
20% 25V
C366
S
1-123-343-00 CAP, ELECT
33
20%
35V
C367
s
1-107-085-00
CAP,
MICA 100P 5%
50V
C368
s
1-123-343-00
CAP,
ELECT 33
20% 35V
C369
s
1-123-356-00
CAP,
ELECT
10
20% 50V
C370
s
1-123-379-00
CAP,
ELECT 0.47
20%100V
C371
s
1-123-306-00 CAP, ELECT 47
20%
10V
C37
2
s
1-123-332-00
CAP,
ELECT 47 20%
25V
C373
s
1-108-579-00
CAP,
MYLAR 0.01 5%
50V
C37
4
s
1-123-307-00
CAP, ELECT
100 20% 10
V
C375
s
1-108-603-00
CAP,
MYLAR 0.1 5%
50V
C376
s
1-123-330-00
CAP,
ELECT
22
20% 25V
C377
s
1-123-369-00
CAP,
ELECT 4.7 20% 63V
C37
8
s
1-123-307-00
CAP,
ELECT 100 20%
10V
C379
s
1-123-332-00
CAP,
ELECT 47 20%
25V
C380
s
1-123-336-00
CAP,
ELECT 470 20%
25V
C381
s
1-123-336-00
CAP, ELECT 470
20% 25V
C382
s
1-123-333-00
CAP,
ELECT 100 20%
25V
C383 s
1-123-333-00
CAP,
ELECT 100 20%
25V
CN301
0
1-564-250-00
PIN, CONNECTOR 15P
CN302
0
1-560-156-00
PLUG,
CONNECTOR 12P
CN303 0
1-560-123-00
PLUG,
CONNECTOR
3P
CN304 0
1-560-123-00
PLUG,
CONNECTOR
3P
CN305
0
1-560-123-00
PLUG, CONNECTOR 3P
CN306 0
1-560-123-00
PLUG,
CONNECTOR
3P
CN307 0
1-560-123-00
PLUG,
CONNECTOR
3P
CN308 0
1-560-124-00
PLUG, CONNECTOR 4P
CN309
0
1-560-128-00
PLUG, CONNECTOR 8P
D301
s
8-719-911-19
DIODE 1SS119
D302
s
8-719-911-19
DIODE 1SS119
D303 s
8-719-911-19
DIODE 1SS119
D304
s
8-719-911-19
DIODE 1SS119
D305 s
8-719-911-19
DIODE 1SS119
D306 s
8-719-911-19
DIODE 1SS119
D307 s
8-719-911-19
DIODE 1SS119
D308
s
8-719-911-19
DIODE 1SS119
D309 s
8-719-911-19
DIODE 1SS119
D310
s
8-719-911-19
DIODE 1SS119
D311 s
8-719-911-19
DIODE 1SS119
D312
s
8-719-911-19
DIODE 1SS119
D313 s
8-719-911-19
DIODE
1SS119
D314
s
8-719-911-19
DIODE 1SS119
D315
s
8-719-911-19
DIODE 1SS119
D316 s
8-719-911-19
DIODE 1SS119
D317
s
8-719-100-43
DIODE
RD7.5E-B1
D318 s
8-719-911-19
DIODE 1SS119
D319
s
8-719-911-19
DIODE 1SS119
IC301 s
8-759-745-61
IC
NJM4560D-D
IC302 s
8-759-745-61
IC
NJM4560D-D
IC303
s
8-759-745-61
IC
NJM4560D-D
IC304 s
8-759-745-61
IC
NJM4560D-D
IC305
s
8-759-745-61
IC NJM4560D-D
IC306
s
8-759-745-61
IC
NJM4560D-D
IC307
s
8-759-745-61
IC
NJM4560D-D
IC308 s
8-759-745-61
IC
NJM4560D-D
IC309 s
8-759-745-61
IC
NJM4560D-D
IC310
s
8-759-745-61
IC
NJM4560D-D
IC311
s
8-759-745-61
IC
NJM4560D-D
IC312
s
8-759-745-61
IC
NJM4560D-D
IC313
s
8-759-745-61
IC
NJM4560D-D
Ref.
No.
SP
Part No.
Description
Q301
S
8-729-312-12
TRANSISTOR 2SC1213A
Q302
S
8-729-306-72
TRANSISTOR 2SD667A
Q3 03 S
8-729-364-72
TRANSISTOR
2SB647
Q304
S
8-729-306-72
TRANSISTOR
2SD667A
Q305 S
8-729-364-72
TRANSISTOR
2SB647
Q306
S
8-729-312-12
TRANSISTOR 2SC1213A
Q307 S
8-729-306-72
TRANSISTOR
2SD667A
Q3
08
S
8-729-364-72
TRANSISTOR
2SB647
Q309
S
8-729-306-72
TRANSISTOR 2SD667A
Q310
S
8-729-364-72
TRANSISTOR
2SB647
Q311 S
8-729-312-12
TRANSISTOR 2SC1213A
Q312 S
8-729-312-12
TRANSISTOR
2SC1213A
Q313 S
8-729-195-23
TRANSISTOR
2SA952
R301
s
1-247-163-00
RES,
CARBON 22K
5% 1/4W
R302 s
1-247-725-11
RES,
CARBON 10K
5%
1/4W
R303
s
1-247-725-11
RES,
CARBON 10K
5%
1/4W
R304 s
1-247-163-00
RES, CARBON
22K
5% 1/4W
R305 s
1-247-725-11
RES,
CARBON 10K
5%
1/4W
R306 s
1-247-725-11
RES, CARBON
10K
5% 1/4W
R307
s
1-247-172-00
RES, CARBON
51K
5% 1/4W
R308 s
1-247-725-11
RES, CARBON
10K 5% 1/4W
R309 s
1-247-725-11
RES, CARBON
10K 5% 1/4W
R310 s
1-247-172-00
RES, CARBON
51K
5% 1/4W
R311 s
1-247-725-11
RES, CARBON
10K
5%
1/4W
R312 s
1-247-725-11
RES, CARBON
10K
5% 1/4W
R313 s
1-247-725-11
RES, CARBON
10K
5%
1/4W
R314 s
1-247-161-00
RES, CARBON 18K 5% 1/4W
R315 s
1-247-725-11
RES, CARBON 10K 5% 1/4W
R316
s
1-247-725-11
RES, CARBON
10K
5% 1/4W
R317 s
1-249-469-11
RES, CARBON
100K
5%
1/4W
R318
si
1
Al-217-391-00
:
I
RES,
FUSE
22
5%
1/4W
R319
si
4,1-217-391-00
:| RES,
FUSE 22
5%
I/4W
R320
s
1-247-696-11
RES, CARBON 47 5%
1/4W
R321 s
1-247-696-11
RES,
CARBON 47
5%
1/4W
R322
s
1-247-696-11
RES, CARBON 47 5% 1/4W
R323
s
1-247-696-11
RES, CARBON 47 5% 1/4W
R324 s
1-247-696-11
RES, CARBON 47 5% 1/4W
R325 s
1-247-713-11
RES,
CARBON IK
5%
1/4W
R326 s
1-249-469-11
RES, CARBON
100K
5%
1/4W
R327
s
1-247-713-11
RES, CARBON
IK
5%
1/4W
R328
s
1-247-162-00
RES, CARBON
20K
5% 1/4W
R329
s
1-247-120-00
RES, CARBON
360
5%
1/4W
R330 s
1-247-146-00
RES, CARBON 4.3K 5% 1/4W
R331 s
1-247-725-11
RES, CARBON
10K
1% 1/4W
R332 s
1-247-725-11
RES, CARBON
10K
1%
1/4W
R333
si
'
A
1-217-391-00
i I
RES, FUSE 22 5% 1/4W
R334
si
ji| A
1—217
—3
95—
00
i
§
RES,
FUSE 47
5%
1/4W
R335 s
1-247-725-11
RES, CARBON
10K
1% 1/4W
R336 s
1-247-725-11
RES, CARBON 10K 1% 1/4W
R337
s
1-247-725-11
RES, CARBON 10K 5% 1/4W
R338
s
1-247-725-11
RES, CARBON 10K
5%
1/4W
R339 s
1-247-688-11
RES, CARBON 10 5% 1/4W
R340 s
1-247-688-11
RES, CARBON
10
5%
1/4W
R341 s
1-247-725-11
RES,
CARBON
10K
1%
1/4W
R343
s
1-247-725-11
RES,
CARBON 10K
5%
1/4W
R344
s
1-247-725-11
RES, CARBON 10K
1%
1/4W
R345
s
1-247-725-11
RES, CARBON
10K
1%
1/4W
R346 s
1-247-725-11
RES, CARBON
10K
5% 1/4W
R347 s
1-247-725-11
RES, CARBON
10K
5%
1/4W
R348 s
1-247-688-11
RES, CARBON
10
5%
1/4W
R349
s
1-247-688-11
RES,
CARBON 10
5%
1/4W
R350
s
1-247-725-11
RES, CARBON
10K
1% 1/4W
