– 33 –
R911 1-216-864-11 METAL CHIP 0 5% 1/16W
R912 1-216-864-11 METAL CHIP 0 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB551 1-233-961-11 RES, NETWORK (CHIP TYPE) 1K
RB552 1-233-979-11 RES, NETWORK (CHIP TYPE) 1M
RB801 1-233-977-11 RES, NETWORK (CHIP TYPE) 470K
< VIBRATOR >
X601 1-781-038-21 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
* 1-670-710-11 SWITCH BOARD
*************
< CAPACITOR >
C802 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN802 1-785-217-21 CONNECTOR, FPC (ZIF) 9P
< DIODE >
D801 8-719-051-01 LED CL-170HR-CD-T (OPERATE)
< RESISTOR >
R814 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R815 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R816 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R817 1-216-835-11 METAL CHIP 15K 5% 1/16W
R818 1-216-839-11 METAL CHIP 33K 5% 1/16W
< SWITCH >
S301 1-762-079-11 SWITCH, SLIDE (DIGITAL MEGA BASS)
S801 1-771-483-21 SWITCH, PUSH (1 KEY) (OPEN/CLOSE)
S802 1-762-078-11 SWITCH, SLIDE (HOLD c)
S803 1-762-078-11 SWITCH, SLIDE (AVLS)
S804 1-771-138-21 SWITCH, KEY BOARD (p)
S805 1-771-138-21 SWITCH, KEY BOARD (+”)
S806 1-771-138-21 SWITCH, KEY BOARD (=)
S807 1-771-138-21 SWITCH, KEY BOARD (VOLUME +)
S808 1-771-138-21 SWITCH, KEY BOARD (VOLUME -)
************************************************************
MISCELLANEOUS
**************
17 1-670-708-11 SWITCH FLEXIBLE BOARD
53 1-670-707-11 CLV FLEXIBLE BOARD
! 63 X-4949-164-1 OPTICAL PICK-UP BLOCK ASSY
M901 8-835-594-02 MOTOR, DC (SPINDLE)
M902 1-698-764-21 MOTOR, SLED (SLED) (INCLUDING GEAR)
R1001 1-216-789-11 METAL CHIP 2.2 5% 1/16W
(NEW TYPE)
• Note:
Use R1001 only with Ver.3 of microprocessor (IC801).
Using R1001 with other microprocessor versions will cause operating
errors so be sure to remove it.
You can check the version with Test Mode (page 7).
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-475-831-21 REMOTE CONTROL UNIT (RM-MZE55) (GOLD)
1-475-831-51 REMOTE CONTROL UNIT (RM-MZE55) (BLUE)
(HK)
1-528-918-11 BATTERY CASE
! 1-528-866-11 BATTERY CHARGER (BC-9HP2) (HK)
! 1-528-580-21 BATTERY CHARGER (BC-7HT) (Tourist)
1-528-743-11 BATTERY, NICKEL HYDROGEN
! 1-569-007-11 ADAPTOR, CONVERSION 2P (Tourist)
3-008-521-01 CASE, BATTERY CHARGE
3-865-053-11 MANUAL, INSTRUCTION (SPANISH,CHINESE)
(Tourist)
3-865-053-21 MANUAL, INSTRUCTION (ENGLISH,FRENCH)
(Tourist)
3-865-053-61 MANUAL, INSTRUCTION (ENGLISH,CHINESE)
(HK)
3-865-053-71 MANUAL, INSTRUCTION (JAPANESE,
KOREAN) (Tourist)
4-972-888-01 CASE, CARRYING
8-953-218-90 HEADPHONE MDR-E838SP//K SET
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SWITCHMAIN
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
