Sony MZ-E55 - 3 Disassembly; Upper Panel Assy; Mechanism Deck Section

– 4 –
SECTION 3
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
3-1. UPPER PANEL ASSY
r
The equipment can be removed using the following procedure.
3-2. MECHANISM DECK SECTION
set
Main board, Audio board Switch board
Mechanism deck section
Optical pick-up block ASSY
Upper panel ASSY
4 Screw (M1.4) step
5 Screws (M1.4) precision pan
3
7
1
2
6
OPEN knob
Upper panel ASSY
Lid, Battery case
Main unit
1 Screws (M1.4) precision pan
3 CLV flexible board
4 Flexible
board
Main unit
Main board
Slider ASSY, Open
Mechanism deck section
2
5
