Ref. No. Part No. Description Remark
PHA-1A/1AEU
2929
VOLUME
< VIBRATOR >
X401 1-814-304-11 VIBRATOR, CRYSTAL (12 MHz)
X601 1-814-304-11 VIBRATOR, CRYSTAL (12 MHz)
*************************************************************
VOLUME BOARD
*************
When the VOLUME board is defective, replace the PLATE MIDDLE ASSY (SV)
(Ref. No. VOL1).
*************************************************************
MISCELLANEOUS
**************
BAT1 X-2591-595-1 BATTERY ASSY (SV)
(Including Label (Battery recycle)) (See Note 2)
MA1 X-2591-592-1 CASE AND PC BOARD ASSY (SV)
(Including MAIN board, Sheet, Label)
(PHA-1A: US, CND) (See Note 1)
MA1 X-2591-593-1 CASE AND PC BOARD ASSY (SV)
(Including MAIN board, Sheet, Label)
(PHA-1A: E, AUS, RU) (See Note 1)
MA1 X-2591-594-1 CASE AND PC BOARD ASSY (SV)
(Including MAIN board, Sheet, Label) (PHA-1A: CH)
(See Note 1)
MA1 X-2591-616-1 CASE AND PC BOARD ASSY (SV)
(Including MAIN board, Sheet, Label) (PHA-1A: LA)
(See Note 1)
MA1 X-2592-229-1 CASE AND PC BOARD ASSY (SV)
(Including MAIN board, Sheet, Label) (PHA-1AEU)
(See Note 1)
VOL1 X-2591-560-1 PLATE MIDDLE ASSY (SV)
(Including VOLUME board)
WR1 1-848-857-11 CABLE WITH CONNECTOR (8 pin)
(MAIN - VOLUME board)
WR2 1-848-858-11 CABLE WITH CONNECTOR (3 pin)
(MAIN - HP JACK board)
*************************************************************
Note 2: When removing the battery assy (Ref. No. BAT1) from the frame
sheet or battery cushion, the battery assy (Ref. No. BAT1) cannot
be reused. Besure to replace them with new parts.
MAIN
Ver. 1.1
Note 1: When replacing the MAIN board or case, be sure to replace both
parts simultaneously.
Among the repair parts, the MAIN board and case are supplied
as one unit.
