25
PHA-1A/1AEU
SECTION 5
ELECTRICAL PARTS LIST
A-2072-474-A HP JACK BOARD, COMPLETE (PHA-1A)
***********************
When the HP JACK board is defective, replace the complete mounted board.
*************************************************************
X-2591-592-1 MAIN BOARD, COMPLETE (SV)
(PHA-1A: US, CND) (See Note)
X-2591-593-1 MAIN BOARD, COMPLETE (SV)
(PHA-1A: E, AUS, RU) (See Note)
X-2591-594-1 MAIN BOARD, COMPLETE (SV) (PHA-1A: CH)
(See Note)
X-2591-616-1 MAIN BOARD, COMPLETE (SV) (PHA-1A: LA)
(See Note)
********************
(Included in CASE AND PC BOARD ASSY (SV)
(Ref. No. MA1))
< CAPACITOR/JUMPER RESISTOR >
C1 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C2 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C3 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C4 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C5 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C7 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C8 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C9 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C10 1-100-765-21 ELECT CHIP 10uF 20% 16V
C11 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C13 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C14 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C15 1-100-765-21 ELECT CHIP 10uF 20% 16V
C16 1-100-765-21 ELECT CHIP 10uF 20% 16V
C17 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C19 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C20 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C021 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C26 1-100-765-21 ELECT CHIP 10uF 20% 16V
C27 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C35 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C050 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C052 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C101 1-127-963-21 FILM CHIP 470PF 5% 50V
C102 1-135-814-21 FILM CHIP 0.0039uF 5% 16V
C103 1-127-963-21 FILM CHIP 470PF 5% 50V
C104 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C106 1-128-993-21 ELECT CHIP 22uF 20% 10V
C201 1-127-963-21 FILM CHIP 470PF 5% 50V
C202 1-135-814-21 FILM CHIP 0.0039uF 5% 16V
C203 1-127-963-21 FILM CHIP 470PF 5% 50V
C204 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C206 1-128-993-21 ELECT CHIP 22uF 20% 10V
C207 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C208 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C217 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C228 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C300 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C301 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C303 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C304 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C305 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C308 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C309 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C310 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C311 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C312 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C313 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C362 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C402 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C403 1-118-045-11 CERAMIC CHIP 2.2uF 10% 25V
C404 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C407 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C408 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C409 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C410 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C411 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C412 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C414 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C416 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C417 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C418 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C421 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C500 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C501 1-100-765-21 ELECT CHIP 10uF 20% 16V
C502 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C504 1-165-492-21 ELECT CHIP 100uF 20% 10V
C505 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C514 1-118-402-11 CERAMIC CHIP 0.0012uF 10% 50V
C515 1-116-741-11 CERAMIC CHIP 0.47uF 20% 10V
C516 1-116-741-11 CERAMIC CHIP 0.47uF 20% 10V
C517 1-116-741-11 CERAMIC CHIP 0.47uF 20% 10V
C518 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C520 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Refer to service manual supplement-1 for
electrical parts list (HP JACK board, MAIN
board, VOLUME board) of PHA-1AEU.
HP JACK MAIN
Note: When replacing the MAIN board, be sure to replace the case simultaneously.
Among the repair parts, the MAIN board and case are supplied as one unit.
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
Ver. 1.1
