Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PHA-1A/1AEU
26
C521 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C522 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C523 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C524 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C525 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C526 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C527 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C529 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C530 1-165-492-21 ELECT CHIP 100uF 20% 10V
C541 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C542 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C551 1-100-765-21 ELECT CHIP 10uF 20% 16V
C552 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C553 1-116-741-11 CERAMIC CHIP 0.47uF 20% 10V
C554 1-118-412-11 CERAMIC CHIP 220PF 10% 50V
C555 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C556 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C558 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C559 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C560 1-165-492-21 ELECT CHIP 100uF 20% 10V
C561 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C564 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C565 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C566 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C567 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C568 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C569 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C570 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C571 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C572 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C573 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C574 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C575 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C576 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C577 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C580 1-116-741-11 CERAMIC CHIP 0.47uF 20% 10V
C581 1-116-741-11 CERAMIC CHIP 0.47uF 20% 10V
C608 1-164-848-11 CERAMIC CHIP 8PF 0.5PF 50V
C609 1-164-848-11 CERAMIC CHIP 8PF 0.5PF 50V
C610 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C611 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C621 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C622 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C623 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C624 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C625 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C626 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C627 1-116-726-11 CERAMIC CHIP 2.2uF 10% 25V
C628 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C629 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C630 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C631 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C632 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C633 1-216-864-11 SHORT CHIP 0
C703 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C706 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C707 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C709 1-116-741-11 CERAMIC CHIP 0.47uF 20% 10V
C710 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C711 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C712 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C713 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C714 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C716 1-116-724-11 CERAMIC CHIP 4.7uF 20% 6.3V
C719 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C720 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C721 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C722 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C724 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
< CONNECTOR >
CN001 1-779-806-21 CONNECTOR 8P
CN002 1-785-946-21 CONNECTOR 3P
CN601 1-842-915-11 USB CONNECTOR (MICRO B)
(INPUT (FOR PC/WALKMAN/Xperia))
CN602 1-844-269-11 CONNECTOR, USB (A)
(INPUT (FOR iPhone/iPad/iPod))
CN701 1-842-915-11 USB CONNECTOR (MICRO B) (DC IN 5V)
CN702 1-843-522-11 HOUSING, CONNECTOR
< DIODE >
D512 6-502-728-01 DIODE RSX101M-30FJTR
D513 6-502-728-01 DIODE RSX101M-30FJTR
* D514 6-503-573-01 DIODE 1SS400SMGJT2R
* D515 6-503-573-01 DIODE 1SS400SMGJT2R
* D602 6-503-573-01 DIODE 1SS400SMGJT2R
* D603 6-503-573-01 DIODE 1SS400SMGJT2R
D701 6-500-122-01 LED CL-375HR/YG-D-TS (POWER/CHG)
* D719 6-503-573-01 DIODE 1SS400SMGJT2R
* D722 6-503-573-01 DIODE 1SS400SMGJT2R
* D723 6-503-573-01 DIODE 1SS400SMGJT2R
< FUSE >
0 F701 1-523-135-31 FUSE (3.15 A/32 V)
< FERRITE BEAD/JUMPER RESISTOR >
FB001 1-469-092-11 FERRITE, EMI (SMD) (1608)
FB002 1-469-092-11 FERRITE, EMI (SMD) (1608)
FB0020 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB003 1-216-864-11 SHORT CHIP 0
FB021 1-400-703-21 EMI FERRITE (SMD) (3216)
FB101 1-400-703-21 EMI FERRITE (SMD) (3216)
< IC >
IC001 (Not supplied) IC LME49860MAX/NOPB (See Note)
IC002 (Not supplied) IC TPA6120A2DWPR (See Note)
IC003 (Not supplied) IC LMP7708MAX/NOPB (See Note)
IC101 (Not supplied) IC TS12A12511DCNR (See Note)
IC201 (Not supplied) IC TS12A12511DCNR (See Note)
IC301 (Not supplied) IC WM8740SEDS/RV (See Note)
IC401 (Not supplied) IC LC87F17C8AUWA-2H (See Note)
IC402 6-715-659-01 IC PST8428UL
IC403 (Not supplied) IC MFI337S3959 (See Note)
IC500 (Not supplied) IC TPS61087DRCR (See Note)
IC501 (Not supplied) IC MAX1846EUB+T (See Note)
IC502 (Not supplied) IC TPS7A4700RGWR (See Note)
IC503 (Not supplied) IC TPS7A3301RGWR (See Note)
IC504 6-719-070-01 IC MM3411A50URE
IC505 (Not supplied) IC NJM2827F3-05 (TE1) (See Note)
MAIN
Note: The parts that are transcribed by “Not supplied” cannot replace with single.
When these parts are damaged, replace the complete mounted board.
