Sony PHA-1A - Page 27

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PHA-1A/1AEU
2727
IC506 (Not supplied) IC RP601Z330A-E2-F (See Note)
IC507 (Not supplied) IC RP402N501E-TR-FE (See Note)
IC508 6-715-661-01 IC PST8431UL
IC509 6-715-164-01 IC TPS2553DBVR
IC510 6-719-198-01 IC MM3411A33URE
IC511 6-710-375-01 IC 74LVC1G175GW-125
IC512 6-719-198-01 IC MM3411A33URE
IC601 (Not supplied) IC CM6631A (See Note)
IC602 (Not supplied) IC SST39LF010-55-4C-WHE (See Note)
IC701 (Not supplied) IC BQ24073RGTR (See Note)
IC702 (Not supplied) IC PIC16F1455T-I/ML (See Note)
@ IC704 6-717-898-11 IC BD6047AGUL-E2
IC705 6-715-661-01 IC PST8431UL
< JUMPER RESISTOR >
JC101 1-216-864-11 SHORT CHIP 0
JC103 1-216-864-11 SHORT CHIP 0
JC104 1-216-864-11 SHORT CHIP 0
JC105 1-216-864-11 SHORT CHIP 0
JC106 1-216-864-11 SHORT CHIP 0
JC109 1-216-296-11 SHORT CHIP 0
JC111 1-216-864-11 SHORT CHIP 0
JC113 1-216-864-11 SHORT CHIP 0
JC114 1-216-864-11 SHORT CHIP 0
< COIL >
* L500 1-400-846-11 INDUCTOR 3.3uH
L503 1-482-011-11 INDUCTOR 1uH
L504 1-457-942-11 COIL, CHOKE 2.2uH
L551 1-416-944-21 COIL, CHOKE 15uH
< FET >
Q001 (Not supplied) FET SSM6N58NU, RSONYF
(See Note)
Q002 (Not supplied) FET SSM6N58NU, RSONYF
(See Note)
Q401 6-553-619-01 FET RAF040P01TCL
Q402 6-551-346-01 FET LSK3541FS8T2L
Q403 6-551-346-01 FET LSK3541FS8T2L
Q404 6-553-619-01 FET RAF040P01TCL
Q405 6-551-346-01 FET LSK3541FS8T2L
Q501 6-553-619-01 FET RAF040P01TCL
Q502 6-553-338-01 FET RU1C001UNTCL
Q503 6-553-619-01 FET RAF040P01TCL
Q508 6-553-338-01 FET RU1C001UNTCL
Q509 6-553-619-01 FET RAF040P01TCL
Q510 6-551-346-01 FET LSK3541FS8T2L
Q511 6-551-346-01 FET LSK3541FS8T2L
Q512 6-551-346-01 FET LSK3541FS8T2L
Q513 6-551-346-01 FET LSK3541FS8T2L
Q595 6-553-619-01 FET RAF040P01TCL
Q702 6-551-346-01 FET LSK3541FS8T2L
Q703 6-551-346-01 FET LSK3541FS8T2L
Q710 6-553-338-01 FET RU1C001UNTCL
Q711 6-553-619-01 FET RAF040P01TCL
Q712 6-553-338-01 FET RU1C001UNTCL
Q713 6-553-338-01 FET RU1C001UNTCL
Q716 6-551-346-01 FET LSK3541FS8T2L
Q717 6-551-346-01 FET LSK3541FS8T2L
Q718 6-551-346-01 FET LSK3541FS8T2L
Q719 6-551-346-01 FET LSK3541FS8T2L
Q720 6-551-346-01 FET LSK3541FS8T2L
Q721 6-551-346-01 FET LSK3541FS8T2L
Q722 6-551-346-01 FET LSK3541FS8T2L
Q723 6-553-619-01 FET RAF040P01TCL
< RESISTOR/CAPACITOR >
R4 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5 1-218-953-11 METAL CHIP 1K 5% 1/16W
R101 1-250-504-11 METAL CHIP 2.4K 1% 1/16W
* R102 1-250-506-11 METAL CHIP 3K 1% 1/16W
R103 1-250-475-11 METAL CHIP 150 1% 1/16W
* R104 1-250-506-11 METAL CHIP 3K 1% 1/16W
R105 1-250-475-11 METAL CHIP 150 1% 1/16W
R106 1-250-504-11 METAL CHIP 2.4K 1% 1/16W
R107 1-218-941-81 METAL CHIP 100 5% 1/16W
R111 1-218-969-11 METAL CHIP 22K 5% 1/16W
R112 1-218-953-11 METAL CHIP 1K 5% 1/16W
R113 1-218-979-11 METAL CHIP 150K 5% 1/16W
R114 1-218-953-11 METAL CHIP 1K 5% 1/16W
R115 1-220-210-11 METAL CHIP 200K 5% 1/16W
R116 1-218-990-81 SHORT CHIP 0
R117 1-216-797-11 METAL CHIP 10 5% 1/10W
R118 1-218-990-81 SHORT CHIP 0
R119 1-218-953-11 METAL CHIP 1K 5% 1/16W
R141 1-220-210-11 METAL CHIP 200K 5% 1/16W
R201 1-250-504-11 METAL CHIP 2.4K 1% 1/16W
* R202 1-250-506-11 METAL CHIP 3K 1% 1/16W
R203 1-250-475-11 METAL CHIP 150 1% 1/16W
* R204 1-250-506-11 METAL CHIP 3K 1% 1/16W
R205 1-250-475-11 METAL CHIP 150 1% 1/16W
R206 1-250-504-11 METAL CHIP 2.4K 1% 1/16W
R207 1-218-941-81 METAL CHIP 100 5% 1/16W
R211 1-218-969-11 METAL CHIP 22K 5% 1/16W
R212 1-218-953-11 METAL CHIP 1K 5% 1/16W
R213 1-218-979-11 METAL CHIP 150K 5% 1/16W
R214 1-218-953-11 METAL CHIP 1K 5% 1/16W
R215 1-220-210-11 METAL CHIP 200K 5% 1/16W
R216 1-218-990-81 SHORT CHIP 0
R217 1-216-797-11 METAL CHIP 10 5% 1/10W
R218 1-218-990-81 SHORT CHIP 0
R219 1-218-953-11 METAL CHIP 1K 5% 1/16W
R241 1-220-210-11 METAL CHIP 200K 5% 1/16W
R302 1-250-519-11 METAL CHIP 10K 1% 1/16W
R303 1-218-941-81 METAL CHIP 100 5% 1/16W
R304 1-218-941-81 METAL CHIP 100 5% 1/16W
R305 1-218-941-81 METAL CHIP 100 5% 1/16W
R306 1-218-941-81 METAL CHIP 100 5% 1/16W
R307 1-218-941-81 METAL CHIP 100 5% 1/16W
R308 1-218-990-81 SHORT CHIP 0
R309 1-218-990-81 SHORT CHIP 0
R310 1-218-990-81 SHORT CHIP 0
R311 1-218-990-81 SHORT CHIP 0
R316 1-218-977-11 METAL CHIP 100K 5% 1/16W
R318 1-218-977-11 METAL CHIP 100K 5% 1/16W
R319 1-218-969-11 METAL CHIP 22K 5% 1/16W
R320 1-218-969-11 METAL CHIP 22K 5% 1/16W
R321 1-218-977-11 METAL CHIP 100K 5% 1/16W
R406 1-250-459-11 METAL CHIP 33 1% 1/16W
R407 1-250-459-11 METAL CHIP 33 1% 1/16W
R409 1-208-663-11 METAL CHIP 150 0.5% 1/16W
MAIN
@ Replacement of IC704 on the MAIN board
used in this unit requires a special tool.
Note: The parts that are transcribed by “Not supplied” cannot replace with single.
When these parts are damaged, replace the complete mounted board.
