7
PHA-1A/1AEU
2. ELECTRICAL PARTS LIST
A-2081-095-A HP JACK BOARD, COMPLETE (PHA-1AEU)
***********************
When the HP JACK board is defective, replace the complete mounted board.
*************************************************************
X-2592-229-1 MAIN BOARD, COMPLETE (SV) (PHA-1AEU)
(See Note)
********************
(Included in CASE AND PC BOARD ASSY (SV)
(Ref. No. MA1))
< CAPACITOR/JUMPER RESISTOR >
C1 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C2 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C3 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C4 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C5 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C7 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C8 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C9 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C10 1-100-765-21 ELECT CHIP 10uF 20% 16V
C11 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C13 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C14 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C15 1-100-765-21 ELECT CHIP 10uF 20% 16V
C16 1-100-765-21 ELECT CHIP 10uF 20% 16V
C17 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C19 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C20 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C021 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C26 1-100-765-21 ELECT CHIP 10uF 20% 16V
C27 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C35 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C050 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C052 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C101 1-127-963-21 FILM CHIP 470PF 5% 50V
C102 1-135-814-21 FILM CHIP 0.0039uF 5% 16V
C103 1-127-963-21 FILM CHIP 470PF 5% 50V
C104 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C106 1-128-993-21 ELECT CHIP 22uF 20% 10V
C201 1-127-963-21 FILM CHIP 470PF 5% 50V
C202 1-135-814-21 FILM CHIP 0.0039uF 5% 16V
C203 1-127-963-21 FILM CHIP 470PF 5% 50V
C204 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C206 1-128-993-21 ELECT CHIP 22uF 20% 10V
C207 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C208 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C209 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C217 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C228 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C300 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C301 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C303 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C304 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C305 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C308 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C309 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C310 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C311 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C312 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C313 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C362 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C402 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C403 1-118-045-11 CERAMIC CHIP 2.2uF 10% 25V
C404 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C407 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C408 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C409 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C410 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C411 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C412 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C414 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C416 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C417 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C418 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C421 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C500 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C501 1-100-765-21 ELECT CHIP 10uF 20% 16V
C502 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C504 1-165-492-21 ELECT CHIP 100uF 20% 10V
C505 1-118-417-11 CERAMIC CHIP 0.1uF 10% 16V
C514 1-118-402-11 CERAMIC CHIP 0.0012uF 10% 50V
C515 1-116-741-11 CERAMIC CHIP 0.47uF 20% 10V
C516 1-116-741-11 CERAMIC CHIP 0.47uF 20% 10V
C517 1-116-741-11 CERAMIC CHIP 0.47uF 20% 10V
C518 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C520 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C521 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C522 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Refer to original service manual for electri-
cal parts list (HP JACK board, MAIN board,
VOLUME board) of PHA-1A.
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
Note: When replacing the MAIN board, be sure to replace the case simultaneously.
Among the repair parts, the MAIN board and case are supplied as one unit.
HP JACK MAIN
