Sony RCD-W3 User Manual

Recording on CDR
19
Finalizing a CD-R or CD-
RW disc
Finalizing completes the recording of a disc. It
enables you to play the disc on other players.
(The player must be CD-RW compatible. )
When a recording is finished, a CD-R or CD-
RW disc must be finalized. Once that is done, a
CD-R disc may not be changed or added to.
CD-RW discs are locked once they are
finalized, and must be unfinalized to permit
additional recording or erasure.
When using the remote, set SELECT to CDR
for operations on DECK B.
1 Press FINALIZE.
The “FINALIZE” indicator will begin to
flash, and the PLAY, PAUSE, and REC
indicators light up for about 8 seconds.
Erasing enters standby mode.
FINALIZE
2 Press H while the “FINALIZE”
indicator is flashing.
Finalizing starts. During finalizing, “ TOC
WRITE” appears in the display and the
remaining time for finalizing appears in the
display. When the finalizing process is
finished, the total track number and the total
playing time appear in the display and the
TOC (red) indicator lights off.
Notes
• The TOC (red) indicator appears on the front panel
display if the disc you put in DECK B has not been
finalized. Check the indicator each time before
finalizing.
• Once finalizing process starts, you cannot stop in
the middle of the process.
• Do not turn off the recorder or disconnect the
recorder from the power source in the middle of the
finalizing process.
FINALIZE

Sony RCD-W3 Specifications

Power

power requirements	U.S.A. and Canada 120 V AC, 60 Hz
power requirements other countries	110 – 240 V AC, 50/60 Hz
power consumption	20 W

Audio Specifications

frequency response	20 Hz – 20, 000 Hz (±0.5 dB)
signal-to-noise ratio	More than 100 dB
dynamic range	More than 95 dB

Inputs

analog in impedance	47 kilohms
rated input	330 mVrms
minimum input	125 mVrms

Outputs

analog out rated output	2 Vrms (at 50 kilohms)
load impedance	over 10 kilohms
phones	28 mW, 32 ohms

Weight and Dimensions

dimensions	430 × 108 × 368 mm
mass	4.6 kg
