Sony RCD-W3 User Manual

24
Specifications
DECK A (the CD player section)
System Compact disc and digital
audio system
Laser Semiconductor laser (λ =
780 nm)
Emission duration:
continuous
Frequency response 20 Hz – 20,000 Hz (±0.5
dB)
Signal-to-noise ratio More than 100 dB
Dynamic range More than 95 dB
DECK B (the CD-R and CD-RW
recording section)
System Compact disc digital audio
system
Laser Semiconductor laser (λ =
780 nm)
Emission duration:
continuous
Playable discs CD, CD-R, CD-RW
Recordable discs CD-R, CD-RW (for music
use)
Frequency response 20 to 20,000 Hz ±0.5 dB
Signal-to-noise ratio Over 100 dB during
playback
Dynamic range More than 95 dB during
playback
Inputs
ANALOG IN
(Phono jacks) impedance 47 kilohms
Rated input 330 mVrms
Minimum input
125 mVrms
DIGITAL OPTICAL IN
(Square optical connector jack)
Optical wavelength
660 nm
Outputs
ANALOG OUT
(Phono jacks) Rated output 2 Vrms (at
50 kilohms)
Load impedance over
10 kilohms
OPTICAL DIGITAL OUT
(Square optical connector jack)
Wavelength 660 nm
Output level -18 dBm
PHONES
(Phone jacks) 28 mW, 32 ohms
General
Power requirements
U.S.A. and Canada 120 V AC, 60 Hz
Other countries 110 – 240 V AC, 50/60
Hz
Power consumption 20 W
Dimensions (approx.) (w/h/d) incl. projecting parts
and control
430 × 108 × 368 mm
Mass (approx.) 4.6 kg
Supplied accessories
See page 5.
Design and specifications are subject to change
without notice.
Sony Corporation Printed in China

Sony RCD-W3 Specifications

Power

power requirements	U.S.A. and Canada 120 V AC, 60 Hz
power requirements other countries	110 – 240 V AC, 50/60 Hz
power consumption	20 W

Audio Specifications

frequency response	20 Hz – 20, 000 Hz (±0.5 dB)
signal-to-noise ratio	More than 100 dB
dynamic range	More than 95 dB

Inputs

analog in impedance	47 kilohms
rated input	330 mVrms
minimum input	125 mVrms

Outputs

analog out rated output	2 Vrms (at 50 kilohms)
load impedance	over 10 kilohms
phones	28 mW, 32 ohms

Weight and Dimensions

dimensions	430 × 108 × 368 mm
mass	4.6 kg
